High Effective Gold Machinery Equipment Rotary Mobile Gold Trommel Screen
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Quality Guarantee Rotary Type Biomass Wood Chips Trommel Screen Firewood Trommel Screen
-
Portable Gold Mining Screening Sand And Gold Trommel Screen Equipment
-
Hot Selling Product Screen Variety Of Materials As Compost Wood Chips And Soil Waste Mobile Trommel Screen
-
Screening Compost Wood Chips Topsoil Cattle And Sheep Dung Mobile Trommel Screen Belt Conveyor
-
Factory Sales High Quality Mobile Gold Mining Screen Big Capacity Trommel Screen for Sell
-
Hot Selling Mini Mobile Alluvial Gold Screening Placer Gold Washing Gold Trommel Screen
Product Description
High Effective Gold Machinery Equipment Rotary Mobile Gold Trommel Screen
Product Description
Features of our gold mining machinery equipment:
1. 100% high quality.
2. Lower initial investment costs (compare prices).
3. Operation cost saving (excellent durability and simple mechanical structure).
4. Reduce any additional costs in the future (high productivity and mobility).
5. GTS series can accurately select gold powder, the highest yield rate is 98%.
6. Long-term uninterrupted operation and strong gold collection ability.
7. Easy to operate and easy to maintain.
Gold mining trommel screen working principle:
1. Input of raw materials: Raw materials inputted through the entrance of the hopper will be pushed into the trommel screen by thestrong water pressure of the shower equipped in the hopper.
2. Selection and cleaning of raw materials: Raw materials of the trommel screen will be cleaned and selected by the rotation of trommel screen and by watering of the shower inside, run into the gold dust separate panel.
3. Collecting of gold dust separated Soil and sands with lighter specific gravity will flow away but gold dusts with greater
specific gravity will be staying in the gathering mat to be collected.
Main technical parameter
Model | Capacity (t/h) | Diameter (mm) | Length (mm) | Discharge (mm) | Input (mm) | Dimension ((mm) |
GMTS0519 | 5-10 | 500 | 1910 | 0-100 | ≤300 | 3000x1000x1800 |
GMTS1020 | 10-30 | 1000 | 2000 | 0-100 | ≤300 | 3390×1400×2140 |
GMTS1225 | 30-50 | 1200 | 2500 | 0-100 | ≤300 | 4146×1600×2680 |
GMTS1545 | 50-120 | 1500 | 4500 | 0-100 | ≤400 | 8160×2300×2500 |
GMTS1548 | 80-150 | 1500 | 4800 | 0-100 | ≤400 | 8460×2300×2500 |
GMTS1848 | 100-200 | 1800 | 4800 | 0-100 | ≤400 | 8460×2300×2700 |
GMTS2060 | 200-350 | 2000 | 6000 | 0-100 | ≤400 | 9680×2300x3420 |
