High Performance Factory Price Rotary Topsoil Drum Sifter Sieve Machine Mobile Topsoil Trommel Screen
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1994
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Own Factory High Recovery Rate Mobile Small Gold Trommel Screen Gold Washing PlantNegotiableMOQ: 1 -
Manufacturer Supplier Gold Ore Processing Gold Washing Machine Trommel ScreenNegotiableMOQ: 1
-
Portable Small Processing Wash Mining Equipment Diamond Gold Mining Trommel ScreenNegotiableMOQ: 1
-
High Quality Factory Price Mobile Compost Drum Sifter Sieve Mobile Compost Trommel ScreenNegotiableMOQ: 1
-
2022 New Design Factory Price Mobile Firewood Drum Screen Firewood Mobile Trommel ScreenNegotiableMOQ: 1
High Performance Factory Price Rotary Topsoil Drum Sifter Sieve Machine Mobile Topsoil Trommel Screen
The mobile trommel screening machine is a screening equipment developed by our company for small and medium-sized and light materials such as topsoil, compost, wood chips, cow dung, sand and gravel.
It has the following characteristics:
1. Smooth operation and low noise;
2. Simple structure, maintenance Convenient;
3. The screen holes are not easy to block;
4. The screening efficiency is high;
5. The screen has a long service life and is easy to replace.
Structure and Principle
The mobile trommel screen is mainly composed of hopper, screen drum, idler assembly, transmission part, discharge conveyor, brush, underframe, rear axle, traction, diesel generator, control cabinet, protective cover and other parts.
The basic working principle of the trommel screen: the material is poured into the silo by the loader, and transported to the trommel screen by the conveyor on the silo, and then the motor reducer drives the idler to rotate the screen cylinder, and the material particles in the screen cylinder follow the screen. The drum rotates to a certain height, is thrown and dropped by gravity, and is filtered through the screen to form a screening. Finally, the screened materials are transported to different places by different conveyors.
Model |
Trommel diameter |
Trommel length |
capacity |
Weight |
Dimensions |
MTS1230 |
1200mm |
3000mm |
60m3/h |
3210kg |
5.4*2.1*2.7m |
