Small Capacity 2t/h Iron Powder Rotary Drum Dryer Desulfurization Gypsum Dryer With Cyclone Dust Collector and Fan

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Products Description

Small Capacity 2t/h Iron Powder Rotary Drum Dryer Desulfurization gypsum dryer with Cyclone Dust Collector and Fan

Three-drum dryer is also called three-cylinder dryer and triple-drum dryer. It has improved internal structure of monocular dryer, which prolongs the time of pre-drying of wet materials and wet materials in the machine, thus improving 50% to 80% of production
capacity compared with original monocular dryer.

Type of Three Pass Dryer	SBD-625	SBD-6215	SBD-6220
Drying capacity	6-8t/h	10-15t/h	20-25t/h
Length	2500mm	2700mm	5000mm
Diameter of drum	2200mm	2600mm	2600mm
Motor powder	5.5kw	7.5kw*1	7.5kw*2
Reducer model	XWD-5	ZQ350	ZQ350*2
Speed of drum rotation	4-10r/min	4-10r/min	4-10r/min
Moisture of end products	<5%	<5%	<5%
Max.temperature inside	700-750℃	700-750℃	700-750℃
Outlet temperature	60-80℃	60-80℃	60-80℃
Burning coke quantity kg/t sand	7	7	7

You can click here to get preferential prices and more product details!

Product Application

The Rotary Drier is widely used in the field of building materials, metallurgies, chemical industry, cement and so on.

It can dry slag, coal powder, mining powder, clay, sand, limestone and so on. It is made of rotary body, lifting blade, driving device,
supporting device etc. The dryer has advantages of reasonable structure, high efficiency, low energy consumption and convenient for transportation...

Drying Materials: Powder, coal, sand, clay, slag, etc.

The Rotary Drier is widely used in the field of building materials, metallurgies, chemical industry, cement and so on.

Product &Details

The Cylinder

Name: Cylinder
Material: Use high quality carbon steel or customer specified steel

Internal structure: designed with internal blades and other devices

Seamless welding

Main Features

Name: Cylinder
Brand: Hengchang
Material: high quality steel plate, customer can specify steel plate thickness and steel plate material

Machine Parts

Name: The base
Brand: Hengchang
Material: high quality steel plate, customer can specify steel plate thickness and steel plate material

Main Features

Name:The whole dryer
Brand:Hengchang
Rotary dryer consists of the cylinder, before and after the roller circle, a large gear, gear roll, drag roller, a small gear, a
feeding device, lifting plate, reducer, motor, feeding devices and other components.

You can click here to get preferential prices and more product details!

Working Principle

1.The material first goes into the inside drum, because there are the spiral shape boards fixed in the drum, when the dryer make rotary working, the spiral shape board will stir the material and make the material do movement.
2.When the material reaches the right side of the drum, it will go into the second drum for further drying.
3.The same working principle, the material then goes into outside drum, during the drying working process, the material will make three times drying, so the material can be dried completely in this process. (drum rotary dryer)

Company Information & Certification

Hengchang headquarters is located in the industrial park in Gongyi City. It covers a total area of 150,000 square meters,including 100,000 square meters of standarized workshop. There are more than 200 sets of various large and medium-sized metal processing lathe, riveting machine, welding equipment and assembly equipment. We have more than 300 workers, including more than 20 middle and senior technicians. Hengchang is mainly focus on 4 series products: stone crusher machines, sand making equipment, powder grinding mills, mineral processing equipment and their spare parts. Every year, Baichy can turn out 1,000 sets of crushers and 10,000 tons of crusher parts..

Customer Visit & Our Service

(A) Pre-sale services:

Act as a good adviser and assistant of clients, enable them to get rich and generous returns on their
investments.

1.Select equipment model; 2.Design and manufacture products according to clients' special requirement;

3.Train technical personnel for clients;

4.Services during the sale;

(B)Provide considerate services to minimize clients' worries:

1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;

3.Train the first-line operators;

4.Examine the equipment;

5.Take initiative to eliminate
the troubles rapidly;

6.Provide perfect service;

7.Provide technical exchanges...

(C).After-sale services:Provide considerate services to minimize clients' worries:
1.Assist clients to prepare for the first construction scheme;
2.Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
5. Take initiative to eliminate
the troubles rapidly;
6. Provide perfect service;
7. Provide technical exchanges...

Customer Site

Our machine has been sold to Germany, Australia, Japan, Mexico, Philippines, Indonesia, Russia, Uganda, Uzbekistan, Zimbabwe, etc. and our products are well received by customers. Welcome to inquiry! (rotary drum dryer)

Packing &Delivery

Packaging Details:

Standard export packing, Spare parts in wooden case, big machines loaded incontainer,large machines use nude packing, cover with plastic cloth. We export through QingdaoPort, also can be nominated by customer. We have superior cargo agent
to arrange thesea shipment for each client, competitive price, secure transportation. Delivery Time:

We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 10 to 20 working days. (drum rotary dryer)

FAQ

1.In order to provide you the suitable quotation we need to know the following information:
1).What is the raw material for the production line?
2).What is the capacity per hour you required?
3).What is the maximum input size of the raw material?
4).What is the output size and application for the final product? Once we get your answers, I can provide you the best quotation immediately.

2.What about Warranty of the products?
Hengchang Machinery grants our customers a Twenty-four-month-period warranty from the date of delivery for machines exported from us.
During the warranty period, in case any defect of material or workmanship occurred with spare parts in normal operation, we will at our discretion replace or repair the defective parts freely.

3.The reason you choose Hengchang Machinery :
1).Professional manufacturer of supplying Dry mortar production line equipment,exterior wall paint, drying machine equipment, high speed dispersing machine, true stone paint filling machine, packaging machine equipment and other mechanical equipment
2).Experienced and professional R&D team and manufacturing team;
3).Professional sales team consisted of dedicated, dynamic and innovative people with international version.
4).Professional logistics service ensuring safety and timely delivery of products all over the world through ocean, airline, road and railway.

4.What is the difference between your machine and others’?
Every machine is unique and has its pros and cons, as is every mine site. We can help you decide your unique situation and decide
which tool is right for your job.

5.If you want to know more about our machine equipment, please send us inquiry or contact us directly.
