Feed-Through Assembly vents do not have filters, but require vent tubing to be

attached and routed accordingly. These are:

• 2 Column Vents (CV1 and CV2)

• 1 Sample vent (S1, S2, S3 and S4)

• 1 Gauge Port Vent (GPV)

1.3.4 Analytical Module

The modular design of the analytical module (P/N 2102172-xxx) is enhanced by

the single bolt removal feature. This module may also be broken down into the GC

module (P/N 2102033-xxx), manifold assembly (P/N 2102149-xxx) and analytical

processor assembly (P/N 2101831-xxx). The GC module also features single bolt

removal.

The analytical module comes in two configurations: 12V and 24V.

Of the subassemblies that comprise the analytical module, GC module and

manifold assembly come in two configurations: 12V and 24V.

In Figure 1—9 the user can see the analytical module assembly removed from the

enclosure.

1.3.4.1 Features

• High-speed Serial Interface to Digital Controller Board

• 32-bit Digital Signal Processor

• Flash Memory

• Analog to Digital Conversion Circuits

• Digital Oven Temperature Controller

2101510-002 – rev. AD Page 1–11

• Digital Auxiliary Heater Controller (optional Feed-Through Heater)

• Dual Digital Pressure Regulators

• Sample Pressure Sensor

• Pressure Sensors (100 PSI max.)

• Thermal Conductivity Detectors

• System Level Voltage Monitoring

• Analytical Processor Board Level Temperature Sensor

• LED Board Status Indicators
