Help CenterKUC711AE 3BHB004661R0001
Related Products
Brand: ABB
Type:KUC711AE 3BHB004661R0001
Origin: the Swiss
Warranty: 365 days
Colour: new/used
Shipping method: Courier delivery
Alarms 5 different alarms: Gas and Moisture Alert (Hi), Gas and Moisture Alarm (HiHi), Service Alarm (sensor, temp, …) Gas alarms can be set on gas level reached or on hourly or daily trend (gas level rate of change) Moisture alarms can be set on level reached or average level Alarms can also be configured for optional additional analogue inputs or for calculation results from optional transformer models 5 dry contact relays (type C, SPDT), NO/NC, 3A@250Vac resistive load, 3A@30Vdc resistive load Manual Sampling Easily accessable external oil sampling port for glass syringe with Luer stop cock ENVIRONMENT Conditions Operating ambient temperature -40°C to +55°C (-40°F to +131°F) Operating ambient humidity 0-95% RH, non-condensing Oil temperature at valve -40°C to +105°C (-40°F to +221°F) with finned heat sink adapter option Oil pressure at valve 0-700KPa (0-100psi) Vacuum resistant sensor Enclosure Rating NEMA Type 4X certified, meets requirements of IP66 Power Requirements 90–132 Vac or 180–264 Vac switch mode universal power supply, 47–63 Hz, 650VA max
Mechanical Has a 1.5” NPT male thread but can also mount on a 1” or 2” female NPT valve using optional adapters Dimensions 315 x 219 x 196 mm 12.4 x 8.63 x 7.72 " Installed weight 7.5Kg (16.5lb) Shipping weight 9.0Kg (20lb) OPTIONS Finned heat sink adapter (1.5”) for use when ambient temp > 40°C (104°F) or oil temp > 90°C (194°F). Valve adaptor 1” to 1.5” or 2” to 1.5” Transformer models calculations Analogue input cards, 4-20mA, 10V load max, isolated to 2000Vac RMS Dual digital input cards for dry contacts, internal wetting 24Vdc, isolated 2000Vac Analogue output cards, 4-20mA, 10V load max, isolated to 2000Vac RMS PSTN analogue modem V92/56K GSM/GPRS wireless modem Network Ethernet communication using copper (RJ-45) or multimode fibre optic (ST) Oil temperature sensor, magnetic mount, (4-20mA) Split core load CT (4-20mA) Ambient temperature sensor (4-20mA)
