Free-standing installation
Overloading and water shortage and full ice alarm
High efficiency CFC free compressor, Economical
and low energy consumption
Air cooling system, ventilate from side
Ice production testing condition: Ambient temperature
21°C ,inlet water temperature 10°C
Model | BIMF-20 | BIMF-30 | BIMF-40 | BIMF-50 |
Ice Production Capacity | 20kg/24h | 30kg/24h | 40kg/24h | 50kg/24h |
Ice Storage Capacity | 5kg | 5kg | 10kg | 10kg |
Ice shape | Flake | Flake | Flake | Flake |
Electrical Supply | AC220/50Hz | AC220/50Hz | AC220/50Hz | AC220/50Hz |
Power | 265W | 280W | 420W | 425W |
Refrigerant | R134a/95g | R134a/100g | R134a/115g | R134a/120g |
Condensing system | Air cooling | Air cooling | Air cooling | Air cooling |
Overall Dimensions | 330X503×607mm | 330×503×607mm | 398×542×700mm | 398×542×700mm |
Packing Dimensions | 390×560×640mm | 390×560×640mm | 460×610×760mm | 460×610×760mm |
Net weight | 32kg | 32kg | 40kg | 40kg |
Housing Material | 304/2B Stainless Steel | 304/2B Stainless Steel | 304/2B Stainless Steel | 304/2B Stainless Steel |
Housing Material | 304/2B Stainless Steel | 304/2B Stainless Steel | 304/2B Stainless Steel | 304/2B Stainless Steel |
Material of baseboard& backboard | galvanized steel | galvanized steel | galvanized steel | galvanized steel |
Ice Bin | Food Grade ABS | Food Grade ABS | Food Grade ABS | Food Grade ABS |
Insulation | Expanded Polystyrene | Expanded Polystyrene | Expanded Polystyrene | Expanded Polystyrene |
Evaporator | Nickel Plated copper | Nickel Plated copper | Nickel Plated copper | Nickel Plated copper |
Inlet water | Drinking water | Drinking water | Drinking water | Drinking water |
Water pressure | >0.15~0.3MPa | >0.15~0.3MPa | >0.15~0.3MPa | >0.15~0.3MPa |
Inlet diameter | 0.75inch | 0.75inch | 0.75inch | 0.75inch |
Pipeline material | Food Grade plastic | Food Grade plastic | Food Grade plastic | Food Grade plastic |
