Home > Instruments & Meters > Lab Utensil and Disposable > Test Tube > BN-600MCS-3 Pulsed Field Electrophoresis System
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
1994
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BIMF-20 BIMF-30 BIMF-40 BIMF-50 Flake Ice MakerNegotiableMOQ: 1 -
BIMF-60 BIMF-80 BIMF-85 Flake Ice MachineNegotiableMOQ: 1
-
BIMF-100-I BIMF-100-II BIMF-130-I BIMF-130-II Commercial Ice MakerNegotiableMOQ: 1
-
BIMF-150 BIMF-200 BIMF-250 BIMF-300 Flake Ice MachineNegotiableMOQ: 1
-
BIMB-20--BIMB-50-I Bullet Cube Ice MachineNegotiableMOQ: 1
Product Description
Technical specififications
Gel Size(W×L):120×120(mm)
Sample volume:(2.0mm)9、13wells
No. of Samples: 9~13
Buffer Volume:~3000(ml)
Net weight:85.2(kg)
Sample volume:(2.0mm)9、13wells
No. of Samples: 9~13
Buffer Volume:~3000(ml)
Net weight:85.2(kg)
Dimension (L×W×H):Power supply：280×240×110(mm)
Output control allocation:465×445×100(mm)
Constant temperature circulator:350×200×480(mm)
Pulsed tank:465×445×142(mm)
Output control allocation:465×445×100(mm)
Constant temperature circulator:350×200×480(mm)
Pulsed tank:465×445×142(mm)
Features
* Isolated fragment: 100bp-6Mb.
* Voltage gradient: Max. 9.5V/cm, increment 0.1v/cm.
* Max. current: 0.5A.
* Max. power: 300W.
* Pulse angle: ±120°,±180°, Having the field reversal function.
* Pulse width: 1~9999s or programmed pulse or 1~20s line increase pulse.
* Module timer: 1min~99hours 59min.
* Temperature ranges: 10°C~30°C, Accuracy ≤ ±0.5°C
* Temperature detection: Detect the temperature of buffer solution directly, error≤ ±0.1°C.
* Cycling module: Built-in buffer cycling system.
* Control function: Dual core microprocessor intelligent control, Editable program and automatic connection function, Open lid power-off protection, overload and no-load protection, automatic memory function, automatic shutdown function
* Voltage gradient: Max. 9.5V/cm, increment 0.1v/cm.
* Max. current: 0.5A.
* Max. power: 300W.
* Pulse angle: ±120°,±180°, Having the field reversal function.
* Pulse width: 1~9999s or programmed pulse or 1~20s line increase pulse.
* Module timer: 1min~99hours 59min.
* Temperature ranges: 10°C~30°C, Accuracy ≤ ±0.5°C
* Temperature detection: Detect the temperature of buffer solution directly, error≤ ±0.1°C.
* Cycling module: Built-in buffer cycling system.
* Control function: Dual core microprocessor intelligent control, Editable program and automatic connection function, Open lid power-off protection, overload and no-load protection, automatic memory function, automatic shutdown function
.Power supply module
Molding shell, touch keys, dual core microprocessor intelligent control, with the program editing and automatic connection
function, open cover power-off protection function, overload protection, no-load automatic memory function, the function of automatic shutdown function.
function, open cover power-off protection function, overload protection, no-load automatic memory function, the function of automatic shutdown function.
Output mode control allocation module
In the control of CPU intelligent control unit, control of farm output in accordance with the procedure of mode of pulse electric power module, the controlled pulsed field voltage, current, electric field, electric field angle duration, output to a specific sub electrode pulse electrophoresis tank.
Electrophoresis tank module
Pulse field gel electrophoresis electrode composed of hexagonal, each side electrode are respectively provided with 3 independent sub electrode. The pulsed field electrophoresis pulsed field driving power supply output with pulsed field electrophoresis tank to specific points on the electrode, pulsed field strength, electric field, electric field angle conversion time meet the experimental pulse field gel electrophoresis experiments need. At the same time control buffer cooling cycle unit to realize the constant temperature operation of the electrophoretic run, ensure the electrophoresis experiment effect.
Constant temperature circulator module
With buffer refrigeration circulation pump, control electrophoresis temperature effectively, the use of high efficiency, log-life service.
