Laboratory Testing Equipment Digital Yarn Strap Tension Meter
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2015
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Physics Laboratory Equipment Belt Strap Rope Tension MeterNegotiableMOQ: 1 -
Orthodontic Tension Gauge Spring Line Screen Printing Tension MeterNegotiableMOQ: 1
-
Portable 5000N Cable Tension Meter for High Speed Rail IndustryNegotiableMOQ: 1
-
Digital Display Portable Coating Ultrasonic Thickness GaugeNegotiableMOQ: 1
-
Digital Portable Ndt Ultrasonic Flaw Detector With High PrecisionNegotiableMOQ: 1
Product Description
laboratory testing equipment digital yarn strap tension meter
Product introduction：
ND digital pressuremeter tension tester is a kindof special equipment to measure wind towers,
signal transmission and power transmission systems rope tension. It has characters of high precision, easy to operate, easy to carry, etc. also it has many kinds of test modes, convenient to testing.
Users can also input gravity acceleration value to make the test more accurately.
Features
1:High precision, high resolution.
2:N (Newton), kg (kg), lb (lb) three testing units for selection, mutual conversion.
3:Gravity acceleration setting function---.
4:Peak holding function---Maintain peak display until manual reset.
5:Automatic peak function---Maintain peak value can be removed automatically after 2 seconds.
6:Can set upper and lower limit value to make statistical analysis, the value more than comparative value, the alarm buzzer will alarm.
7:Data stored function, we can store 896 test values.
8:10 minutes without operating automatic shutdown, green initiative.
9 :Six digit Big screen display.
More Details Photos
Specification
Model |
ND1T |
ND2T |
ND5T |
ND10T |
ND20T |
||||
Max load value |
10KN |
20KN |
50KN |
100KN |
200KN |
||||
Load division value |
0.01KN |
0.01KN |
0.01KN |
0.1KN |
0.1KN |
||||
0.001Mg |
0.001Mg |
0.001Mg |
0.01Mg |
0.01Mg |
|||||
0.001Klb |
0.001Klb |
0.001Klb |
0.01Klb |
0.01Klb |
|||||
Error of indication |
±0.5% |
±1.0% |
|||||||
Accuracy |
According to the ropes characteristics of different forms, precision is the 2%-6% of the full range. |
||||||||
Unit |
N(KN) Kg(Mg or T) Lb(Klb) |
||||||||
Output interface |
Rs232 Nine holes socket |
||||||||
Power |
Rechargeable batteries Battery voltage(100V-240V) |
||||||||
Sensor structure |
S type or cylinder shape high-accuracy sensor (External) |
||||||||
Operating temperature |
-20℃+60℃ |
||||||||
Transportation temperature |
-20℃+60℃ |
||||||||
Relative temperature |
10%-90% RH |
||||||||
Work environment |
No seismic focus and corrosive medium around |
||||||||
Net weight |
About 400g+weight of sensor |
||||||||
Size |
230 * 66 * 36mm |
||||||||
