3000N Digital Wire Tension Meter for Elevator
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2015
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NANBEI Clinical Examination Auto Ophthalmic Digital Phoropter PriceNegotiableMOQ: 1 -
Horizontal Test Stand Electrical Test Equipment Force Gauge Test StandNegotiableMOQ: 1
-
High Precision Touch Screen Digital Torque Wrench Calibrator MachineNegotiableMOQ: 1
-
Digital Electronic Torque Wrench TesterNegotiableMOQ: 1
-
6mm 10mm 20mm 40mm Steel Wire Rope Tension MeterNegotiableMOQ: 1
Product Description
Digital Elevator Rope Tension Meter
Product introduction：
Elevator rope tension tester is mainly used in elevator wire rope tension test . To check and adjust each wire rope of elevator in the process of installation, check before acceptance and annual inspection to ensure its tension as consistent as possible, thereby prolonging the service life of the traction wheel . The tension tester can also be applied to the bridge with sling, tower wiring,overhead wire ,index wire rope and other tension test.
Feature
1.The instrument has stable performance and high accuracy,when the tested wire rope are consistent with wire rope tension tester data ,the measuring precision can be 5%.
2.Light weight ,simple structure,easy to operate,suitable for any occasion.
3.The instrument has 3 preset wire rope diameter model, just need to choose the correct wire rope number when measuring .
4.LCD display shows the value force,it is more convenient to reading.
6.Three units:N,Kg and Lb can switch into each other .
More Details Photos
Specification
Model |
NGZ-Y-3000 |
NGZ-Y-5000 |
|||||||||
Number |
1 |
2 |
3 |
1 |
2 |
3 |
|||||
Diameter |
φ6 |
φ8 |
φ10 |
φ11 |
φ13 |
φ16 |
|||||
Range |
3000N |
5000N |
|||||||||
Min. Load Division Value |
1N |
||||||||||
Scientific measuring range |
10%~90% |
||||||||||
Accuracy |
≦±5% |
||||||||||
Power |
7.2V 1.2V×6 NI-H Battery |
||||||||||
Charger |
Input ：AC 100~240V Output：DC 12V 500mA |
||||||||||
Weight （Kg） |
1.4 kg |
||||||||||
Recommendations
Packing & Delivery
Company Profile
Customer Concerns
FAQ
Q1: Why Choose NANBEI ?
(1).Professional manufacturer with more than 13 years experience
(2).Exported to more than 97% Countries
(3).Turnkey Solution is no problem
Q2:OEM,ODM acceptable or not?
Absolutely Yes
Q3:What's kind of Payment terms for customer choosing?
T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ...
Q4:Can we visit your factory online?
Absolutely no problem
Q5:Can online video inspection before shipment?
Absolutely no problem
Q6: what's the MOQ ? Sample order is OK?
MOQ:1 set, sample order is no problem
Q7:What's kind of shipment for customer choosing?
Usually ship by sea, by air, by international express .
We can also provide reasonable solutions according to your transportation requirements
Q8:How to ensure product quality and after-sales service?
We have CE, ISO quality certificate, and SGS authentication.
After-sale service:
1.Warranty : 1 year
2.We supply free part for quality problem in warranty
3.Long life technical support and service
