1800C High Temperature Electric Laboratory Muffle Furnace Price
1.Feature and Description
Thermocouple Model: US imports. the highest temperature can be measured to 1860 ℃ thermocouple, using zirconia protective cover, at 1800 degrees will not drift
Trigger: phase-shifted trigger (with soft start and current limiting)
Current limiting function: no matter how to adjust the heating time, our electric furnace after the transformer secondary current is limited to 160A within the limited protection of the equipment, no matter how you operate, will not burn the equipment.
Soft start function: the current will slowly increase the boot, the impact of heating elements smaller, is conducive to the extension of the life of heating elements
Air switch: the furnace with an air switch, when the current exceeds the open current rating, the air will automatically jump off, the effective protection of the furnace
Stroke switch: the furnace door is equipped with a trip switch, open the door, the power will automatically cut off to prevent the impact of heating components and the risk of electric shock
2.Picture for Our product
| Main Body | |
3.Usage and Application
(1) thermal processing, industrial parts processing, cement, building materials industry, the thermal processing or processing of small parts.
(2) the pharmaceutical industry: for the testing of drugs, pretreatment of medical samples.
(3) Analytical Chemistry: As sample processing in areas such as water quality analysis and environmental analysis. Can also be used for oil and its analysis.
(4) Analysis of coal quality: used to determine moisture, ash, volatile, ash melting point analysis, ash composition analysis, elemental analysis. Can also be used as a general ash furnace.
4.Technical data
| Power | 5.5KW |
| Internal size (DXWXH) | 180X150X150 |
| Power supply voltage | 220V |
| Number of phases | single phase |
| Heating element | 1900 type lKanthal silicon molybdenum rod |
| Control mode | the use of electronic program temperature control instrument |
| Heating rate | ≤ 30 ℃ / Min |
| Recommended heating rate | 15 ℃ / Min |
| Furnace material | 1800 type alumina polycrystalline fiber (alumina content above 95%) Japanese imports |
| Control accuracy | +/- 1 ° C |
| The maximum temperature | 1800 ℃ |
| Rated temperature | 1750 ℃ |
| Surrounded by surface temperature | ≤ 45 ℃ |
5.Packing and Shipping
1.Company Show
2.Factory Show
1.Certification
2.Warranty and After-sale service
♥♥We Supply 1 Year Warranty , And Lifelong Free Technical Guiding And Training♥♥
