TVR Evaporator
- 1 Set / Sets per Month
- Shanghai
- T/T L/C
- 1 days
- Triple-effect Forced Circulation Evaporator for Cobaltous Sulfate Recovery
- MVR Evaporator for Landfill Leachate Treatment
- MVR Evaporator for Ammonium Sulfate Wastewater
- MVR Evaporator for Sodium sulfate wastewater
- Four-effect Falling Film Evaporator for Coffee Extract Concentration
- MVR Evaporator for Extract Concentration
Product Details
Place of Origin: | China | Model Number: | ECMVR-XXXX | Certification: | CE |
After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 12months from the date of completion of installation or 15months from date of delivery, whichever comes earlier | Weight: | Accordingly based on customized specification |
Dimension(L*W*H): | Accordingly based on customized specification | Condition: | New | Voltage: | 380V OR Customized |
Application: | Desalinization | Power(W): | Accordingly based on customized specification | Power Source: | Electric |
Process: | Thermal |
Product Description
TVR Evaporator
TVR (Thermal Vapor Recompression) evaporator takes advantage of thermal compression pump(Venturi) to make use of the secondary steam, thus to reduce steam consumption and achieve purpose of energy-saving.
After the high-pressure steam enters the thermal compression pump, high-vacuum condition is formed inside the thermal compression pump under the action of high-flow steam, sucks the secondary steam from the effect I separator to the thermal compression pump, where the secondary steam is mixed with the secondary steam. And after compression, the mixed steam enters the Effect I heater and acts as heating source.
Live steam of higher pressure (≥0.5Mpa) is required for the thermal compression pump;
The steam consumption reduced by athermal compression pump is equivalent to adding one effect of evaporator, reduce the energy consumption greatly;
The thermal compression pump is free of movingpart, ensures the operational reliability;
The load of the condenser is reducedbecause the evaporation capacity at the final effect decreases.
