Powder air supply valve pocket packing machine:
Product Introduction:
The machine has a high degree of automation, simple operation, equipped with the new research and development of automatic bag unloading device, only the workers inserted into the bag (adapt to the valve pocket) can complete the packaging production process, save labor (3-4 people), reduce the labor intensity of workers, JI large reduce production costs, improve production efficiency. Pneumatic valve port packing machine is suitable for packing powder or fine particles (≤5mm) with good fluidity, using compressed air as the power. Compressed air passes through the atomizer (air cushion) to fluidize the material in the closed container, so as to achieve the role of conveying material. Airtight use of pneumatic rubber valve, through the control of the valve flow area, in order to control the amount of material packaging, to achieve effective and stable packaging accuracy and speed. This PRODUCTION LINE CAN PRODUCE a variety of dry powder products: thermal insulation mortar, bonding mortar, anti-cracking mortar, dry powder binder, self-leveling mortar, dry powder putty and other dry powder material products.
Main Features:
1, automatic microcomputer control, computer intelligent automatic identification, automatic measurement, high sensitivity, stable performance, strong anti-interference ability, accurate weighing;
2. New design, no ram, sinobeam, swimming weight, clamping wheel, clamping pin, tension spring, pull spring and other mechanical weighing mechanism, unlimited reduction of vulnerable parts; Not only reduce the maintenance cost, but also improve the production efficiency;
3. Automatically realize the functions of pressing, filling, closing and dropping bags, stable performance and simple operation;
4, the body is completely sealed and equipped with dust removal port, reasonable structure, durable, truly achieve environmental protection production;
5, the packing machine mainly has single mouth (GZM-AI), double mouth (GZM-AII) two models, by the double mouth can be composed of 4-6 mouth packing machine.
Technical parameters:
1, each mouth output 10-15T /h,2, bag weight error: ±0.2kg, 3, bag weight
