Particle Ton Bag Weighing and Packing Machine

Overview of ton bag packing machine

Ton bag packing machine is used for ton bag packing materials of large weighing packaging equipment, it is a collection of electronic weighing, automatic bag removal, dust removal in YI body multi-purpose packing machine. It has a high degree of automation, high packaging precision, packaging speed can be adjusted, superior structure, hydraulic lifting system is particularly easy to deal with tons of bag packaging, the processing of the last process is very convenient. Ton bag packing machine is suitable for packing tons of material bags in mineral, chemical, building materials, grain and feed industries.

The main structure of ton bag packing machine

Including pneumatic hook clamping system, fast and slow feeding device, weighing device, lifting device, conveying raceway, electrical control and so on.

Technical parameters of ton bag packing machine

Weighing range: 1-2 tons/bag

Bagging capacity: 2-3 points/bag

Accuracy: dynamic weighing ±0.5% Working power supply: 380V, 50HZ, 11kW Air source pressure: 0.5mpa Air consumption: 0.6m3/min Dust removal air volume: 800-2500 m3/min Relative humidity: ≤80% Ambient humidity: -100C-400C

Ton bag scale operation process:

1. Preparation before packaging:

The empty tray is manually placed on the packing position under the weighing platform.

2. Bagging (manual)

The operator presses YI under the "bagging" button, the lifting frame automatically drops to the bagging position, the operator hangs the sling of the bag to the four hooks of the packing machine, and then clamps the feeding port of the bag, so that it is in a completely sealed state, the lifting frame automatically rises to the manual setting, suitable for the pocket bag device.

3, peeling (automatic)

The packing machine automatically removes the weight of the bags

4, fast feeding (automatic)

Packaging machine automatically control to open the feeding mechanism (feeding mechanism: gravity feeding,
