Product Description
DWDM CWDM oadm 4ch fbt fiber optical coupler
1.Wavelength Division Multiplexers --WDM-1310/1550 (FBT):
The fused fiber single mode wavelength division multiplexers combine or separate light at two different wavelengths with high isolation and low insertion loss. These bi-directional WDM products have low polarization dependence. As the deferent isolation, there is three types, WDM(≥20dB), HWDM(≥38dB), SWDM(≥45dB). For the details please refer to them..
2.Specifications
Grade Parameter | Grade "Premium" |
Operating Wavelength (nm) | 1310 & 1550 |
Bandwidth (nm) | ±10 |
Insertion Loss (dB) | ≤ 0.15 (0.10 typ.) |
Isolation (dB) | ≥ 20 |
Polarization Dependent Loss (dB) | ≤ 0.1 |
Thermal Stability (dB/°C) | ≤ 0.002 |
Operating Temperature(°C) | -40 to +85 |
Directivity (dB) | ≥ 60 |
3.Package information
Configuration | 1×2 or 2×2 | ||
Lead length | 1 meter, others on request | ||
Lead Type | 0:250um bare fiber | 1:900um loose tube | 2:3mm loose cable |
Package Dimensions (mm) | A: 3.0×40 | A: 3.0×54 | B: 90×16×9 |
Operating Temperature (°C) | -40 to +85 | -20 to +70 | -20 to +70 |
Our Strength & Quality Assurance
Payment & Shippment & Delivery
1.Payment
2.Shipment:by Sea,by Air,by Express:DHL/UPS/Fedex/EMS/TNT etc
3.Deliverty: 3-5 days after payment dowm.
