DWDM Optical Add-Drop Multiplexer DWDM OADM 1 Fiber In/2 Fiber Out, Steel Tube 0.9mm With SC/APC Connector

DWDM Optical Add-Drop Multiplexer DWDM OADM 1 fiber in/2 fiber out, Steel tube 0.9mm with SC/APC Connector

Features

•  Multiplexing of up to 1 channel on a single fiber
•  High quality film filter technology
•  Secure physical separation between data channels
•  Transparent operation - protocol and topology independent
•  Low insertion loss, half 19”/1U module low profile modular design
•  Passive, no electric power required
•  Simplex LC/UPC for line port
•  Duplex LC/UPC for add/drop (Tx/Rx) port, easily support duplex patch cables between the transceiver and passive unit

Description

•  An optical add-drop multiplexer (OADM) is a device used in wavelength-division multiplexing systems for multiplexing and routing different channels of light into or out of a single mode fiber (SMF). This is a type of optical node, which is generally used for the formation and the construction of optical telecommunications networks.
•  "Add" and "drop" here refer to the capability of the device to add one or more new wavelength channels to an existing multi-wavelength WDM signal, and/or to drop (remove) one or more channels, passing those signals to another network path. An 100GHz DWDM 1 CH OADM may be considered to be a specific type of optical cross-connect.

Applications

• CWDM System
• PON Networks
• CATV Links

Compliance

• Telcordia GR-1209-CORE
• Telcordia GR-1221-CORE
• RoHS

Specifications

Notes:

1. Specified without connectors.

2. Add an additional 0.2dB loss per connector.
