SC/FC/LC/ST/MU/mpo sx/dx fiber optic patchcord
Description
1. Fiber optic patch cords are available in all standard connector styles, all standard fiber types and all standard cable configurations to meet all your interconnection needs. They are available in any length .
2.The patch cord are factory terminated, assembled, tested and inspected prior to shipment.
3.All patch cords are manufactured using OFNR riser grade cable, LSZH, plenum, and premium customized specs available upon request, and 100% factory tested to ensure the performance to meet TIA/EIA-568-8-2, iso11801:2002 and EN 50173-1 standards. All assemblies are tested to meet Telcordia GR326-CORE.
Application:
1. CATV
2. Active dvice termination
3. Telecommunication networks
4. Metro
5. Local Area Networks(LANs)
6. Data Processing networks
7. Test Equipment
8. Premise installations.
9. Wide Area Networks(WANs)
Feature:
1.Low insertion loss and back reflection loss
2.Good echangeability
3.Good Durability
4.High temperature stability.
5.Standard: Telcordia GR-326-CORE
6.Precise connector
7.Excellent mechanical capability
8.Patch cords accord with bellcord GR-326 ,ISO9001,ROHS
Specification:
Mode |
SM |
MM |
|
Polish |
UPC |
APC |
PC |
Insertion Loss |
Typical ≤0.2dB Maximum ≤0.3dB |
≤0.25dB |
|
Return Loss |
≥50dB |
≥65dB |
≥35dB |
Interchangeability |
≤0.2dB |
||
Repeatability |
≤0.1dB |
||
Durability |
≤0.2dB (1000 times mating) |
||
Tensile Strengh |
> 10kg |
||
Temperature |
≤0.2dB (-40+85 sustain 100 hours) |
||
Humidity |
≤0.2dB (+25+65 93 R.H.100 hours) |
||
Ordering options:
Boot (cable size) |
Boot Color |
Fiber Type |
Cable number |
Ferrule |
Length |
|
0.9mm 2.0mm 3.0mm |
Black Green Red |
9/125um SM 50/125um MM 62.5/125um MM OM3 OM4 |
Simplex Duplex Multi-fiber |
PC APC |
Customized |
Note:
(1) The fiber optic patch cords are available in all connector styles
(2) Various color cable available upon customers' request
(3) OS1(9/125um), OM1(62.5/125um), OM2(50/125um) and OM3(50/125um) are available
(4) Any length is available upon request
(5) For jacket, PVC(Riser) is normal and LSZH & Plenum are available
(6) For cable type G655 & G657 are also available
- Quality system of ISO900,CE,FCC,ROHS registration
- Manufacture system
- R&D system
- Purchasing system
- Prompt delivery and remarkable services
- Reasonable prices
- Accept orders according to customer's demands
- Rich experience of OEM & ODM co-operation
- Shipment,payment and delivery
We sincerely invite all interested buyers to visit our company and contact us directly for further information, we will reply you as soon as possible!!!
