Glass Dring Milling Grinding Polish Machine Work Center Glass Cnc Engraving Machine photo-2
Glass Dring Milling Grinding Polish Machine Work Center Glass Cnc Engraving Machine photo-3
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2011
Annual Export Value:
US$5 Million - US$10 Million
Contact Supplier Request Quote Chat Now
Jinan Senke CNC Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Glass dring milling grinding polish machine work center glass cnc engraving machine
Product Description
Main Application
Drilling, Milling, Internal and External grinding and polishing, Writing, Shaped Notching, simple Engraving on glass.
Specification
Model
SK-1325
Stroke
X-axis
2500mm
Y-axis
1300mm
Z-axis
250mm
main spindle to table
60mm
Working table
Size
2500*1300
Maximum capacity
500KG
T slot(quantity×width×space)
25*10*50 or Planar adsorption
Glass thickness
2-19mm
Boby
(Heavy wall square tube)
Welding, heat treatment, vibration stress relief
8-12mm
Stainless steel sheet
1.5mm -2mm
Main spindle(polishing)
Grinding wheel bore diameter
¢22
Speed
3000-12000
Rotation type
Direct connect
Peilin lubrication mode
heat grease
Cooling system
Water cooling
Spindle horsepower
7.5KW
Three-axis motor horsepower
4*1.5kw
Feed speed
X, Y axis fast feed
10m/min
Z axis fast feed
6m/min
Cutting feed speed
10m/min
Accuracy
Positioning accuracy
±0.05
Repeat accuracy
±0.03
Glass sheet size (Max and min)
3000*1500mm
150*150mm(thickness≤4mm)
Weight,
power,
size
Weight
3000KG
Power
380V/50HZ/15KW
size(length×width×height)
4500*2500*1800mm

Accessories
Sucker eight pieces
Positioning six pieces
Aluminum * silicone heat-sealing (self-priming or screw-fastening)
Manual, Servo Manual,
Inverter Manual
