Help CenterKYJG Series Computer Control High Speed Rotogravure Printing Machine
Related Products
-
KYJZ-10-1050 Computerized High Speed Rotogravure Printing PressesNegotiableMOQ: 1 Set -
QDF-H Series Dry Laminating MachineNegotiableMOQ: 1 Set
-
KFHJ-1050/1200 High Speed Dry Laminating MachineNegotiableMOQ: 1 Set
-
KSL-1050 Model Solventless Laminating MachineNegotiableMOQ: 1 Set
-
KWF-1250 Solventless Laminating MachineNegotiableMOQ: 1 Set
Tihs series computerized high speed plastic film automatic rotogravure printing machine is good for plastic film such as BOPP, PET,PE, PVC, and paper ,Al foil materials.
It is most reliable and heavy duty type rotogravure printing machine in China, we adopt latest Japan and European technology, use world top brand electric componnets, reasonable in price and high working performance makes it well accepted by higher grade flexible packaging making industry, if you are looking for hiqh quality and long lasting rotogravure printing machine, it is your best choice model. This series printing machine has been exported to more than 20 countries.
Features:
1) The whole machine is including unwinding unit, printing unit and rewinding unit,
unwinding and rewinding can be separately, the printing color can be
increased or decreased from 4 colors to 12 colors
2) The main machine equipped with 7 motors control.
3) Each unit of computer color registration system is controlled by separating micro-
processor. Horizontal register optional.
4) Shaftless air cylinder clamping style for install printing cylinder
5) Auto splicing system works accurate and reliable, so can save the materials.
6) Printing press rubber roller, charging draw press roller are both adopted with
pneumatic control
7) Pneumatic back pressure moving doctor blade
8) Ink circulating system with air pump, viscosity controller optional.
9) Air shaft for unwinding and rewinding shaft, shaftless optional.
10) Automatic computer color registration system and picture video camera are
equipped in this type printing equipment.
11) We also provide design and printing cylinder for customers.
12) Different type of heating method so can fit for buyer's requirements.
Technical parameter：
Model |
KYJG-850,1050,1250,1500 |
Max unwind diameter |
600mm,750mm,800mm or customized |
Max rewind diameter |
600mm,750mm,800mm or customized |
Max mechanic speed |
200m/min |
Max working speed |
180m/min |
Printing color numbers |
1-15 colors |
Total power |
85-350kw |
Voltage |
380V,50Hz or according to buyer specifications |
We also can make automatic rotogravure printing machine or gravure printing equipment according to buyers' drawings and different requirements to fit for various printing materials.
