Electric motor transformer coil winding machine price
Product description
Horizontal coil winding machine is used for coil winding of big capacity transformers and reactors from 5 tons to 35 tons. The machine can be equipped with vertical and horizontal compacting devices and so the winding is more compact and even, and thus assures the quality of winding coils.
Equipped with advanced electronic counter which can count both positive and reverse turns, and also has power-off memorizing function.
coil winding machine
Item |
WRJ-5 |
WRJ-10 |
WRJ-15 |
WRJ-20 |
WRJ-25 |
WRJ-35 |
|
Max load/t |
5 |
10 |
15 |
20 |
25 |
35 |
|
Max coil diameter/mm |
1500 |
1800 |
2000 |
2800 |
2800 |
3000 |
|
Chuck diameter/mm |
750 |
1000 |
1400 |
1800 |
1800 |
2000 |
|
Distance between chuck and tail/mm |
3000 |
3000 |
3500 |
4600 |
4600 |
4600 |
|
Height of main spindle/mm |
1200 |
1400 |
1600 |
1800 |
1800 |
1800 |
|
Stroke of tail stock/mm |
2000 |
2000 |
2000 |
2600 |
2600 |
2600 |
|
Turning range of compacting device |
35° |
||||||
Stroke of compacting head |
500 |
750 |
750 |
750 |
1040 |
1040 |
|
Speed of main spindle/ r/min |
0-10 |
0-10 |
0-10 |
0-10 |
0-10 |
0-7 |
|
Max. Vertical compacting force/ N |
1200 |
1600 |
1600 |
1600 |
1600 |
1600 |
|
Max. Horizontal compacting force/N |
2500 |
3000 |
3000 |
3000 |
3000 |
3000 |
|
Max. Torque/Nm |
8000 |
15000 |
20000 |
25000 |
30000 |
40000 |
|
coil winding machine
coil winding machine
Our service
One stop service for customized machine
Overseas installation & operating training
One year warranty of the whole machine
Life-long technical support
coil winding machine
