17 Ton 240HP Road Motor Grader New Model GR2405

17 Ton 240HP Road Motor Grader New Model GR2405 photo-1
17 Ton 240HP Road Motor Grader New Model GR2405 photo-2
17 Ton 240HP Road Motor Grader New Model GR2405 photo-3
17 Ton 240HP Road Motor Grader New Model GR2405 photo-4
17 Ton 240HP Road Motor Grader New Model GR2405 photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

17 Ton 240HP Road Motor Grader New Model GR2405

Contact
Alivior Liu
Sales Director
Skype:liying.liu3
Wechat:2806003380
Mobile,Whatsapp: +86-156-0190-8606

Features

The motor grader GR2405 is mainly used for ground leveling, ditching, slope scraping, bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc. It is the necessary construction machinery for national defense construction, mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.

Parameters



Item
GR2405
Basic parameters
Engine model
QSB6.7
Rated power/speed
178kW/2200rpm
Overall dimension (standard)
9300x2625x3420mm
Total weight (standard)
17000 kg
Tire specification
17.5-25
Ground clearance (front axle)
586mm
Space of front and rear axles
6447 mm
Space of middle and rear wheels
1538 mm
Performance
parameters
Forward velocity
5,8,11,19,23,38km/h
Reverse speed
5,11,23km/h
Tractive effort f=0.75
88kN
Maximum gradeability
25%
Tire inflation pressure
260kPa
Working system pressure
22MPa
Transmission pressure
1.85-2.2Mpa
Working parameters
Maximum steering angle of front wheel
±48°
Maximum slant angle of front wheel
±17°
Maximum oscillating angle of front axle
±15°
Maximum oscillating angle of equilibrium box
forwards15°, Reverse15°
Maximum steering angle of frame
±25°
Minimum turning radius
7.3m
Scrape knife
Maximum lift height
480mm
Maximum cutting depth
715mm
Maximum tilt angle
90°
Cutting angle
29°-69°
Angle of revolution
360°
Length & chord height
3965x610mm
Oil filling amount
Coolant
50L
Fuel tank
270L
Engine
24L
Transmission
38L
Equilibrium box
60L
Drive alex
36L
Hydraulic oil
190L
