2022 Evangel China Brand New 14.5Ton Grader Motor 165Hp Motor Grader Gr165 Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Efficiency 10 Ton Combination Vibratory Roller Hydraulic Asphalt Compactor XS103 XS103HNegotiableMOQ: 1 -
10 Ton Wheel Loader With Log Fork Wheel Loader Spare Parts 3 Ton Wheel Loader XS103 XS103HNegotiableMOQ: 1
-
Lower Price 10T Hydraulic Double Drum Vibro Road Roller Asphalt Compactor XS103 XS103HNegotiableMOQ: 1
-
10Ton Full Hydraulic Double Drum Road Roller XS103 XS103H Compactor With Cabin And Air ConditionNegotiableMOQ: 1
-
3~9 Meter Sensor Asphalt Concrete Paver SRP90S PLUSNegotiableMOQ: 1
China Brand New 14.5Ton Grader Motor 165Hp Motor Grader Gr165 price
contact
Contact person:Jin Zou
Mobile/Whatspp/Wechat/Skype:+86 17707042688
Email:jin at
The GR165 adopts Dongfeng Cum-mins 6BTA5.9-C180-II turbocharged diesel engine, which has large output torque and power reserve coefficient and low fuel consumption.
The torque converter has a large torque coefficient, a high efficiency, a wide effective area, and a good joint operation characteristic with the engine.
Energy-saving and noise-reducing: adopt low-speed engine transmission line, low specific fuel consumption of rated point, energy saving and environmental protection; low-speed ratio configuration of transmission system, average fuel consumption reduced by about 8%.
Product Description
| Basic specification | |
| Engine model | D6114 |
| Rated power/speed | 125kW/2300rpm |
| Dimension(LxWxH) | 8900×2625×3470mm |
| Operating weight(Standard) | 15000kg |
| Performance specification | |
| Travelling speed ,forward | 5,8,11,19,23,38 km/h |
| Travelling speed ,reverse | 5,11,23 km/h |
| Tractive force(f=0.75) | 77KN |
| Max. gradeability | 20% |
| Tire inflation pressure | 260 kPa |
| Working hydraulic pressure | 16 MPa |
| Transmission pressure | 1.3~1.8MPa |
| Operating specification | |
| Max. steering angle of front wheels | ±50° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 7.3m |
| Biade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°—70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 3965×610mm |
Pictures of motor grader
