Shantui 110hp Hydraulic Crawler Dozer DH10-C2
Final drive
final drive--2-stage spur gear,speed reduction,splash lubrication
undercarriage system
suspension--swing type of sprayed beam, suspended structure of equalizer bar
NO. Of carrier rollers--2(each side)
NO.of track rollers--7(each side)
NO. Of idler--1(each side)
Track shoe
assembled type--single tooth
pitch--228.6mm
width--560mm
tooth height--80mm
NO. Of track shoes--41(each side)
track gauge--2140mm
ground pressure--0.105Mpa
weight
operating weight--37200kg
with multi-ripper--40975kg
hydraulic control system
Max. Pressure--14Mpa(140kg/m²)
type--gear pump
displacement--335.5L/min
control valve type--guiding valve,raise,hold,lower,float
hydraulic tank--control valve and oil filter inner-installed type
steering system
steering clutch--wet type,multi-disc,spring loaded,hydraulially separated,hand and hydraulic control operated
steering brake--wet type,band brake,foot operated(with hydraulic booster, interconnected with clutch)
coolant and lubricant capacity
working device and attachment
straight-tilt dozer--hydraulically actuated with servo valve
blade supporting method--brace type tilt cylinder on right side
width--4130mm
height--1590mm
Max. Lift above ground--1560mm
Max.drop below ground--560mm
Max.Tilt adjustment--1000mm
3-shank ripper
Max. Digging depth--542mm
Max.lift above ground--883mm
Standard digging angle--45°
variable within range between35°-63°
Max.digging depth of single ripper--1250mm
Max. Lift above ground--965mm
overall dimensions
LXWXH--6880X4130X3725
| Parameter name | DH10-C2 XL (Extended version) | DH10-C2 LGP(Super-wetland version) |
| Performance parameters | ||
| Operating weight (Kg) | 9680kg/21341lb (With traction frame) | 10140kg/22355lb (With traction frame) |
| Ground pressure (kPa) | 44.4 | 34 |
| Engine | ||
| Engine model | QSF3.8 | QSF3.8 |
| Rated power/rated speed (kW/rpm) | 86/2200 | 86/2200 |
| Overall dimensions | ||
| Overall dimensions of machine (mm) | 4442*2860*2885 | 4442*3200*2885 |
| Driving performance | ||
| Forward speed (km/h) | 0~9km/h(5.6mph) | 0~9km/h(5.6mph) |
| Reversing speed (km/h) | 0~9km/h(5.6mph) | 0~9km/h(5.6mph) |
| Chassis System | ||
| Center distance of track (mm) | 1650 | 1790 |
| Width of track shoes (mm) | 460 | 630 |
| Ground length(mm) | 2320 | 2320 |
| Tank capacity | ||
| Fuel tank (L) | 197 | 197 |
