T8led light tube double-sided light-emitting bus station advertising light box-Lant Lighting
T8led lamps emit 360° on both sides, and are widely used in advertising light boxes and other places that need to emit light on both sides. Flexible power supply mode: any two of the four pins of the lamp can be connected to L and N to make the lamp work normally (no single-ended or double-ended). The double-sided led lamp is used for light box advertising, and uses two sides to emit light. , Equivalent to two led lamps, single power drive, reduce costs. For bus stop light box advertising. The number of led tubes remains unchanged. Shenzhen Langte Lighting uses double-sided light-emitting LED tubes to solve this problem very well. The actual use effect is good.
product name
T8led double-sided lamp
Product name |
T8 led double-sided lamp |
Product model |
power |
size |
LED quantity |
Luminous flux |
Product brand |
Langte Lighting |
LT-T8-600SM |
10W |
26*L588 |
120 pcs |
900LM+5% |
Working voltage |
AC100-240V/50-60HZ |
LT-T8-1200SM |
18W |
26*L1198 |
140 pcs |
1800LM+5% |
Color |
Warm2700-3500K |
Public lighting (shopping malls, bus stop advertising light boxes, parking lots, etc.) |
||||
Drive type |
Built-in imported constant current drive |
|||||
Light source type |
3014/2835 SMD lamp beads |
|||||
Shade Type |
Stripe Frosted Cream Optional |
|||||
Material |
6063 aviation aluminum + PC cover |
|||||
Features of dimming led tube double-sided light-emitting parameters:
1. 0~100% brightness adjustment, knob type stepless dimming, convenient and practical.
2. Adjust the light to be soft, stable and delicate, without stroboscopic phenomenon.
1. Photoelectric parameters:
Input voltage: 200-245V
Luminous flux: 834-865LM lm
Power consumption: 18W
Color temperature: 3500-6800K
Size: 300X300mm, 600X600mm
0.6m/0.9m/1.2m
Two, T8led lamp double-sided light-emitting bus station advertising light box
Using Langte led double-sided T8 lamp. It reaches the national standard, the luminous efficiency is more than 100Lm/W, and the life span is 10,000 hours. The above T5 high-efficiency energy-saving lamp adopts three-color rare earth powder fluorescent lamp, which has no radiation, is thinner than T8 lamp, and emits light. Higher efficiency, its light is flicker-free, close to natural light, and has a high color rendering index, the illuminated object is bright in color, clear and bright, and is suitable for long-term workplaces.
Three / light box advertising bus station double-sided luminous dimming led tube
1. A light box for storing advertisements. Everyday people can watch the advertisements on the advertising light box during the waiting process. Some may be sales advertisements, and some may be advertisements that are necessary for our daily life. In short, the bus station advertising light box promotes advertisements This function is really effective.
2. Lighting, many advertising light boxes are now equipped with LED tubes, which can provide lighting at night, making people's shelters safer at night.
Fourth, the characteristics of dimming LED lamps:
0~100% brightness adjustment brightness, knob type stepless dimming, convenient and practical.
Adjust the light soft, stable and delicate, no stroboscopic phenomenon.
——DC drive, power consumption, electro-optical power is close to 90%, and the same lighting efficiency saves 70% of electricity than traditional fluorescent lamps.
——No ultraviolet and infrared radiation, no danger of mercury leakage.
Longevity - 50,000-80,000 hours, 10 times the life of traditional fluorescent lamps.
LED double-sided lamp light, reduce cost, single power drive
Five, installation instructions:
1. Remove the starter and rectifier, and connect the live wire and neutral wire of the mains to the left and right ends of the bracket respectively.
2. The LED lamp is a built-in power supply, the two pins of the G13 interface are in a short-circuit state, and the interfaces at both ends are consistent.
led double-sided lamp
At present, the double-sided lamp mainly produces two-color co-extrusion products of PC materials. The main categories are as follows:
Double-sided tube:
Product Specifications: T5/T6/T8/T10/T12
Light-emitting area: 1/3 light-emitting surface, 1/2 light-emitting surface, 2/3 light-emitting surface, 3/4 light-emitting surface, 4/5 light-emitting surface, 5/6 light-emitting surface
Current stock diameter: 15mm/ 16mm / 20mm/ 26mm/ 30mm /32mm /38mm
