SNS NRC Series Factory Supply Industrial Pneumatic Low Speed Brass Rotary Fitting
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1990
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SNS (SCR Series) Aluminum Alloy Swing Clamp Piston Air CylindersNegotiableMOQ: 1 -
SNS CY1/CY3 Series Stainless Steel Magnetic Coupling Rodless Pneumatic CylinderNegotiableMOQ: 1
-
SNS VHS Residual Pressure Automatic Air Quick Safety Release Valve Used for Air Source Treatment Unit, Chinese ManufactureNegotiableMOQ: 1
-
SNS Brand HFS Series Water Flow Control Pump Digital Pressure SwitchNegotiableMOQ: 1
-
SNS AD Series Pneumatic Automatic Drainer Auto Drain Valve for Air CompressorNegotiableMOQ: 1
SNS NRC Series factory supply industrial pneumatic low speed brass rotary fitting
Banner
Product Description
| Fluid | Compresses Air, if liquid please ask for technical support |
| Proof Pressure | 1.32Mpa (1.35kgf/cm2) |
| Working Pressure Range | 0~0.9Mpa (0~9.2kgf/cm2) |
| Ambient Temperature | 0~60℃ |
| Applicable Pipe | PU Tube |
| Material | Brass |
| Model | ØD | R | F | C | A | B | H | RPM |
| NRC4-M5 | 4 | M5 | 33 | 23.5 | 5 | 45 | 12 | 500 |
| NRC4-M6 | 4 | M6 | 33 | 23.5 | 6 | 46.5 | 12 | 500 |
| NRC4-01 | 4 | PT1/8 | 33 | 23.5 | 8 | 46.5 | 12 | 500 |
| NRC6-M5 | 6 | M5 | 25 | 18.5 | 5 | 44.5 | 14 | 500 |
| NRC6-M6 | 6 | M6 | 25 | 18.5 | 6 | 47.5 | 14 | 500 |
| NRC6-M8 | 6 | M8 | 25 | 18.5 | 8 | 46.5 | 14 | 500 |
| NRC6-01 | 6 | PT1/8 | 25 | 18.5 | 8 | 44.5 | 14 | 500 |
| NRC6-02 | 6 | PT1/4 | 25 | 18.5 | 11 | 47 | 14 | 500 |
| NRC6-03 | 6 | PT3/8 | 25 | 18.5 | 11 | 47 | 14 | 500 |
| NRC8-M5 | 8 | M5 | 33 | 23.5 | 5 | 45 | 17 | 400 |
| NRC8-01 | 8 | PT1/8 | 33 | 23.5 | 8 | 47.5 | 17 | 400 |
| NRC8-02 | 8 | PT1/4 | 33 | 23.5 | 11 | 47.5 | 17 | 400 |
| NRC8-03 | 8 | PT3/8 | 33 | 23.5 | 11 | 48 | 17 | 400 |
| NRC8-04 | 8 | PT1/2 | 33 | 23.5 | 11 | 48 | 17 | 400 |
| NRC10-02 | 10 | PT1/4 | 30 | 22 | 11 | 61 | 22 | 300 |
| NRC10-03 | 10 | PT3/8 | 30 | 22 | 11 | 61 | 22 | 300 |
| NRC10-04 | 10 |
PT1/2 |
30 | 22 | 13 | 61 | 22 | 300 |
| NRC12-02 | 12 | PT1/4 | 30 | 32 | 11 | 62 | 24 | 250 |
| NRC12-03 | 12 | PT3/8 | 30 | 32 | 12 | 62 | 24 | 250 |
| NRC12-04 | 12 | PT1/2 | 30 | 32 | 13 | 63 | 24 | 250 |
Certificate
Packaging & Shipping
FAQ
Q1. Are you a manufacturer or a trading company?A1. We are a leading manufacturer of all pneumatic products. Welcome to visit our factory at any time.
Q2. What’s the payment term?A2. T/T, MasterCard, VISA, E-Checking, Boleto, Pay Later.
Q3. How about the delivery time ?A3. 1-3 days for normal models. For big orders, it takes about 10-15 days.
Q4. What is the standard of package?A4. Export standard package or special package according to customers' requirement.
Q5. What kind of product quality does your factory offer?A5. We are top 3 supplier in Chinese market. We offer top quality to our clients.
Q6. Do you accept OEM business?A6. We do OEM .
Q7. What market do you already sell to?A7. We already ship to Asia, Europe, North America, South America, Africa, Oceania.
Q8. What kind of certificate do you have ?A8. We have ISO9001, CE, CCC, etc.
