Hot Sale High Efficiency ZLG Vibrate Fluidized Bed Dryer for Bentonite

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Applications

• Phamaceutical industry: tablet, capsule, low sugar or no sugar granule of Chinese medicine.

• Foodstuff: cocoa, coffee, milkpowder, juice of granulate, flavoring and so on.

• Other industries: peticide, feed chemical fertilizer, pigment, dyestuff and so on.

• Pharmaceutical industry: power or granule material

• Coating: Granule, protecting coat of pellet, spare color, slow release film, bowel-dissolve coating, ect

Features

• Through powder Granulation, the fluidity is improved and the dust is reduced;

• Through powder Granulation, its solving property is improved;

• The mixing, Granulation and drying can be completed in one step inside the machine;

• The operation of equipment is safe because the anti static filtering cloth is adapted;

• The operating personnel can not be damaged if explosion take place because there is releasing hole;

• The equipment has no dead corner. Therefore the loading and unloading are quick and light and clean. It can meet the requirements of GMP.

Technical parameters

Container	Diameter	mm	300	400	550	700	1000	1200
Capability	Min	Kg	1.5	4	10	15	30	80
Capability	Max	Kg	4.5	6	20	45	90	160
Fan	Capacity	m³/h	1000	1200	1400	1800	3000	4500
	Pressure	mmH₂0	375	375	480	480	950	950
	Power	kw	3	4	5.5	7.5	11	18.5
Steam expenditure		Kg/h	15	23	42	70	141	211
Compressed air expenditure		m³/min	0.9	0.9	0.9	0.9	1.0	1.0
SWeight of the main body		Kg	500	700	900	1000	1100	1300
Steam pressure		Mpa	0.3-0.6
Temperature		°C	(adjustable at the range from room temperature to 120^ )
Working time		min	45 ~ 90 ( decided in accordance with the proplerties of raw materials )
Field		%	>99
Noise		dB(A)	75dB{A)(When installation,main machine is separated from fan)
Size		m	1.0 x 0.6 x2.1	1.2 x 0.7 x2.1	1.25x0.9 x2.5	1.6x1.1 x2.5	1.85x1.4 x 3	2.2x1.65 x3.3
