Calcium Bromide/Boric Acid/Glass Fiber Vibrating Fluidized Bed Dryer
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Low Price Vibrating Fluid Bed Dryer Granule Shape Salt Drying Equipement
-
Hot Sale Vibrating Chemical Equipment Pharmaceutical Continuous Commercial Fluid Bed Dryers
-
Hot Sale ZLG High Efficiency Continuous Vibrating Fluidized Bed Dryer for Food
-
Hot Sale ZLG High Efficiency Continuous Vibrating Fluidized Bed Dryer for NaClO/sodium Chlorate
-
Hot Sale Vibrating Fluidized Bed Dryer for Silica Sand
-
Hot Sale ZLG High Efficiency Continuous Vibrating Fluidized Bed Dryer for Magnesium Citrate/Trimagnesium Dicitrate
Product Description
Product Description
Product Application
Suitable for chemical, pharmaceutical, food, dehydrated vegetables, food, minerals and other industries powder, granular materials, drying, cooling and other operations. Such as: citric acid, monosodium glutamate, borax, ammonium sulfate, compound fertilizer, radish, soybean meal, lees, seeds, slag, sugar and so on.
Model | Area of fluidized-bed(m²) | Temperature of air inlet (°C) | Temperature of air outlet (°C) | Capacity to evaporate moisture (kg/h) | Vibration motor Model Power (Kw) | ||
ZLG3×0.30 | 0.9 | 70-140 | 40-70 | 20~35 | YED10-6 | 0.75x2 | |
ZLG4.5×0.30 | 1.35 | 70-140 | 40-70 | 35~50 | YED10-6 | 0.75x2 | |
ZLG4.5×0.45 | 2.025 | 70-140 | 40-70 | 50~70 | YED16-6 | 1.1x2 | |
ZLG4.5×0.60 | 2.7 | 70-140 | 40-70 | 70~90 | YED16-6 | 1.1x2 | |
ZLG6×0.45 | 2.7 | 70-140 | 40-70 | 80~100 | YED20-6 | 1.5x2 | |
ZLG6×0.60 | 3.6 | 70-140 | 40-70 | 100~130 | YED20-6 | 1.5x2 | |
ZLG6×0.75 | 4.5 | 70-140 | 40-70 | 120~140 | YED20-6 | 1.5x2 | |
ZLG6×0.9 | 5.4 | 70-140 | 40-70 | 140~170 | YED20-6 | 1.5x2 | |
ZLG7.5×0.60 | 4.5 | 70-140 | 40-70 | 130~150 | YED30-6 | 2.2x2 | |
ZLG7.5×0.75 | 5.625 | 70-140 | 40-70 | 150~180 | YED30-6 | 2.2x2 | |
ZLG7.5×0.90 | 6.75 | 70-140 | 40-70 | 160~210 | YED30-6 | 2.2x2 | |
ZLG7.5×1.2 | 9 | 70-140 | 40-70 | 200~260 | YED40-6 | 3.0x2 | |
Main Features
1, The vibration source drived by vibration motor, smooth operation, easy maintenance, low noise, long life.
2, Fluidized symmetry, no dead space and blowing phenomenon, you can get a uniform drying, cooling products.
3, Adjustable good, wide face to adapt. Material layer thickness and in the machine moving speed and full amplitude changes, can achieve stepless adjustment.
4, The damage to the surface of the material is small, can be used for fragile material drying; When dry irregular particles it does not affect the work effect.
5, The use of fully enclosed structure, effectively prevent the material and air cross-contamination, operating environment is very clean.
6, Mechanical efficiency and high thermal efficiency, energy-saving effect is better than the average drying device, it can save 30 to 60% energy.
2, Fluidized symmetry, no dead space and blowing phenomenon, you can get a uniform drying, cooling products.
3, Adjustable good, wide face to adapt. Material layer thickness and in the machine moving speed and full amplitude changes, can achieve stepless adjustment.
4, The damage to the surface of the material is small, can be used for fragile material drying; When dry irregular particles it does not affect the work effect.
5, The use of fully enclosed structure, effectively prevent the material and air cross-contamination, operating environment is very clean.
6, Mechanical efficiency and high thermal efficiency, energy-saving effect is better than the average drying device, it can save 30 to 60% energy.
Certifications
Detailed Images
Machine Parts
Name: The lower part
Brand: Haomai
Original: Jiangsu, China
Sturdy construction with horizontal support rods, strong support rods, diagonal support rods.
Main Features
Name: Peak shape hole perforation plate
Brand: Haomai
Original: Jiangsu, China
Peak shape hole perforation vibrating plate
Machine Parts
Name: vibrating plate
Brand: Haomai
Original: Jiangsu, China
Porforated vibrating plate covered with Meshes.
Main Features
Name: inner surface covered with FRP
Brand: Haomai
Original: Jiangsu
The fluid bed upper and lower part of chamber could covered with FRP for drying Strong acid, strong alkali, strong corrosive material...
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packing & Delivery
Packaging | ||
Size | 11.8 (L) * 2.13 (W) * 2.18 (H) | |
Weight | 7T | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
Packaging | ||
Size | 11.8(L) * 2.13 (W) * 2.18 (H) | |
Weight | 7-9 T | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
