Nano micropore membrane filter cloth filter
Parameter |
||
Filtration T/H |
0.05-20 |
|
Filter pressure mpa |
0.1-0.6 |
|
Filter element |
1, 3, 5, 7, 9, 11, 13, 15, 19,...100 (customizable) |
|
Filter operating temperature C |
< 80 |
|
Material |
SUS304, SUS316, SUS316L |
|
Connection type |
Fast connection or flange |
|
Seal material |
Ethylene propylene trioxide (EPDM), silica gel (silica gel) and fluororubber (PTFE) seals |
|
Seal type |
O-type seal packing ring |
|
Apply to a strainer |
Types 5, 10, 20, 30, 40 222 and 226 |
|
Design Pressure |
1.0 Mpa |
|
Design flow |
2-100m3/H |
|
Surface disposal |
mirror polishing |
|
Main Features
It has the advantages of high filtering accuracy, fast filtering speed, less adsorption, no media falling off, no leakage, acid-alkali corrosion resistance, easy operation, etc. It can remove bacteria and particles in water and liquid medicine for injection, and it can backwash when cleaning. It can be composed of two, three and four filters according to different needs of users to achieve the best filtering effect. It is widely used in medicine, infusion, pure water and biology. Engineering sterilization and clarification.
Description
Membrane technology is a new and high technology with high separation, concentration, purification and purification developed rapidly in recent years. At present, new membrane equipment in China has been continuously developed, studied and applied, and many aspects have approached the advanced level of similar products abroad. As we all know, the filter operation has entered the era of membrane filtration. With the deepening of people's understanding of the filter membrane, membrane filtration will be widely used in most people's filtering operations. Because it can be used as fine filtration equipment alone, but also as other purification devices (such as ion exchange resin, electrodialysis, reverse osmosis and ultrafiltration) to the pretreatment equipment.
Usage method
1. Clean the connecting parts of the filter and the filter thoroughly, install the filter element and the shell correctly.
2.Before starting, check whether the pressure pump is running smoothly, whether the connection is tight and whether the valves are closed.
3. Open the intake valve slowly before starting, exhaust, and then open the outlet valve for normal filtration.
4. If it is found that the pressure difference is greater than 0.1 Mpa or the flow rate decreases significantly, indicating that most of the pore sizes of the filter elements have been blocked, it is suggested that the filter elements be cleaned or replaced by the manufacturer.
5.Membrane filtration is popular among users because of its high accuracy, wide application range, recoil ability, compact structure and simple operation.
Machine Parts
150kg/hour two-stage equipment
Filling Medium: Powdery Medium (Aging Powder)
Applicable liquid temperature: <60 C
Operating pressure < 0.30 Mpa
Intake pipe: 16mm
Outlet pipe: 16mm
Pump power: 80W
Size: Length, width and height 46*21*65cm
Flow: 300 kg/h
Main Features
150 kg/hour single stage equipment
Filling Medium: Powdery Medium (Aging Powder)
Applicable liquid temperature: <60 C
Operating pressure < 0.30 Mpa
Intake pipe: 16mm
Outlet pipe: 16mm
pump power: 80W
Size: Length, width and height 46*21*65cm
Flow: 300 kg/h
Machine Parts
1000 kg/h small double barrel equipment
Filling Medium: Powdery Medium (Aging Powder)
Applicable liquid temperature: <60 C
Operating pressure < 0.30 Mpa
Intake pipe: 25mm
Outlet pipe: 25mm
Pump power: 370W
Size: 55*35*65cm in length, width and height
Flow: 1000 kg/h
Main Features
1500 kg/h double barrel/barrel equipment
Filling Medium: Powdery Medium (Aging Powder)
Applicable liquid temperature: <60 C
Operating pressure < 0.30 Mpa
Intake pipe: 25mm
Outlet pipe: 25mm
Pump power: 370W
Size: 70*35*93 cm in length, width and height
Flow: 1000 kg/h
