Professional Heat Pump Coin Coconut Copra Potato French Fries Dryer Machine Food Drying Machine

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

The spray drying is the technology widely used in the liquid technology shaping and in the drying industry. The drying technology is most suitable for producing the powder, particle or block solid products from the materials, such as: solution, emulsion, soliquoid and pumpable paste states. For this reason, when the particle size and distribution of the final products, their residual water contents, the stacking density and the particle shape must meet the precision standard, the spray drying is one of the most desired technologies.

Detailed Images

Principles

Spiral-shaped hot air evenly into the drying chamber. By passing through the high-speed centrifugal spray at the top of the tower, the material liquid will rotate and be sprayed into the extremely fine mist liquid beads.Through the very short time of contacting the heat air,the materials can be dried into the finished products. The finished products will separator. The waste gas will be discharged from blower.

Every factory machine is precisely debugged by engineers to ensure that it is ready for use after delivery

Type Parameter Item	LPG
Type Parameter Item		5	25	50	100	150	200-2000
Inlet temperature(°C)	140-350 automatically controlled
Outlet temperature(°C)	80-90
Max.water evaporation capacity(kg/h)	5	25	50	100	150	200-2000
Way of atomizing	Compressed air transmission	Mechanical transmission
Rotation speed(rpm)	25000	18000	18000	18000	15000	8000-15000
Diameter of atomizing tray(mm)	50	100	120	140	150	180-340
Heat supply	Electricity	Electricity+ steam	Electricity+steam, fuel oil and gas					Settled by users themselves
Max Electric heating power(kw)	9	36	63	81	99
LWH(m)	1.80.932.2	32.74.26	3.73.25.1	4.64.26	5.54.57	Decided according to be concrete conditions
Dried powder restoring rate(%)	≥95

We can provide a series of detailed materials for mask production pictures, production process videos, drawings, etc.

Professional we can provide sterilizers and packaging machines. Can meet your mass production.

Features

At a high speed of drying, after the spraying of the liquid material , the surface area of the material will be increased greatly. In the hot-air flow, 95%-98%of water can be evaporated at a moment. The time of completing the drying needs only several seconds. Products with good uniformity, mobility and solubility, high purity, good quality. The production procedures are simple and the operation and control are easy. The liquid with the moisture contents 40-60%(for special materials, The contents may reach 90%).can be dried into the powder or particle products once a time. After the drying, there is no need for smashing and sorting, so as to reduce the operation procedures in the production and to enhance the product purity. The product particle diameters, looseness and water contents can be adjusted through changing the operation condition in a certain scope. It is very convenient to carry out the control and management.

We can customize high, medium and low three levels of equipment according to customer requirements

The price is different because of different customization requirements

Technical Parameters

Product Application

Our Company

Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd. (SINOPED) is a professional manufacturer and supplier of pharmaceutical machinery in China. It integrates development, manufacture, sales, after-sale services as a whole, being a professional supplier for dryer granulator, mixer, coater. Solid preparation machine, such as filling machine , capsule machine, tablet machine, packing machine and clean room turnkey project for pharmacy factories. All of machinery fully come up to G M P requirement. Testified by the experience of long-term users, our products have very high stability and reliability, which have been sold to more than 20 regions, cities, and provinces around China and some foreign countries like Asian, European, American. Sinoped have established long-term business relations with many customers and some of them already cooperate as our agent in their countries. For many years, we`re stick to the principle of "Customers First" taken the initiative to manage customers` demands, to develop and research high-quality pharmaceutical equipment, set up a perfect after-sale service system, and brought up the concept of" Star service" The pharmaceutical equipment is worth of your trust, Let`s join hands to co-develop a brilliant future in the 21st century full of opportunities! Brand from concentration——Our pursuit is to product the best cost-effective machines in China. In this 21-century full of opportunities and challenges, SINOPED will provide new equipment and more pragmatic spirit of innovation, cooperate with you and create brilliance!
