Hot Sale Aluminum Window And Door Punching Machine
US$ 980 - 3000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
BAISHUO
Place of Origin:
China
Model Number:
LYA6-50
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
7 days
Related Products
-
3 Axis Cnc Bending Machine For Aluminum And Upvc Profile Aluminum Profile Bending MachineUS$ 4000 - 9000MOQ: 1 Piece -
Aluminum Doors Window Single Head Photo Frame Cutting Saw MachineUS$ 500 - 1000MOQ: 1 Piece
-
Aluminum Doors Window Single Head Cutting Saw MachineUS$ 500 - 1000MOQ: 1 Piece
-
Factory Aluminum Profile Cnc Milling And Drilling Machine For Aluminum Window And DoorUS$ 3900 - 4900MOQ: 1 Piece
-
Automatic Aluminum Profiles Cnc Control Double Head Cutting Window Door Making Mitre Saw MachineUS$ 7000 - 9000MOQ: 1 Piece
Brand Name
BAISHUO
Place of Origin
China
Model Number
LYA6-50
After-sales Service Provided
Engineers available to service machinery overseas
Specification
1.Used for installation of thermobreak aluminum windows and doors and the punching processing of aluminum profiles.
2.Punching process, by changing processing position, various types profiles can be processed.
3.Adopt disk worktable is equipped with six sets of dies. Each die is used at any time by the worktable rotating, which greatly increased the production efficiency.
Technical Parameter
Power supply 380V 50Hz
Motor power 1.5kw
Motor ratational speed 1420r/min
Rated oil pump pressure 16Mpa
Capacity of oil box 20L
Rated pressure 50KN
Die size 250×200×215mm
Close height 185mm
Punching travel 30mm
Overall dimension 900x900x1380(mm)
