Factory Aluminum Profile Cnc Milling And Drilling Machine For Aluminum Window And Door
- 100 Piece / Pieces per Month
- QINGDAO
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
- 7 days
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
- Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
- Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
- Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
- Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
Brand Name: | BAISHUO | Place of Origin: | China | Model Number: | LXF-CNC-800 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1, Used for milling aluminum doors, Windows, curtain walls and industrial aluminum
2, One installation, complete the processing of three surfaces.
3, CNC control processing process, automatic completion of station conversion
4, Wide range of processing width and processing height, to meet the processing of a variety of profiles
5, Specially designed machine bed allows machining of long profiles
6, High - speed spindle with high power and good machining stability
7, Large size linear guide rail is adopted to improve the working accuracy of the machine
8, German special aluminum alloy milling cutter, good quality and high durability
9,Four layers profile milling at one time.
Total power | 3kw |
Work pressure | 0.5-0.6Mpa |
X-axis travel | 1200mm |
Y-axis travel | 260mm |
Z-axis travel | 260mm |
Dimensions | 2800x1900x1700mm |
Weight | 1500kg |
Contact me for details window solution
Whatsapp:0086 15726126528
