MV XLPE Insulated Concentric Bonding Cable
You May Like
Product Details
| Brand Name | Jiangsu Shangshang Cable Group Co., Ltd | Place of Origin | China |
Product Description
APPLICATION：
The cable is mainly used in extra-high voltage cable circuit bonding system as the auxiliary earth cable (return cable). Suitable for fixed installation in outdoor and indoor, direct burial, cable conduit and trench, etc.
STANDARD：
Q/320481SS208, GB/T12706.2, IEC60502-2, or other standards on request.
CONSTRUCTION:
Conductor: Copper, as per IEC60228 class 2
Conductor screen: Semi-conducting compound
Insulation: Cross-linked polyethylene (XLPE)
Insulation screen: Semi-conducting compound
Metallic screen Copper tape
Inner sheath: Extruded PVC, or PE
Concentric conductor: Copper wires
Outer sheath: Extruded PVC, or PE
Note: the construction of inner sheath is suitable for Type VOV cable)
RANGE OF SIZES:
1x50/50mm2 ～ 1x500/500mm2
USAGE CHARACTERISTICS:
 | | | | | |
Rated Voltage Uo/U | Max. conductor temp. in service | Max. short circuit temp. (5s) | Min. installation | Flame-retardant | Min. bending radius when laying 15 (×D) |
SPECIAL FEATURES ON REQUEST:
| | | | | |
Flame retardant | Low smoke | Halogen free IEC60754 | Anti-termite | Anti-rodent | UV resistant |
