The principle of cold mirror is based on its physical definition and is a recognized standard of humidity measurement.Cold mirror dew point instrument has high precision, without drift, long life and good repeatability.
The mirror surface of this cold glass dew point instrument is gilded, and the photoelectric measuring room is made of excellent corrosion resistance to ensure accurate measurement data and adapt to harsh working conditions.
Scope of application
As a standard instrument for humidity dew point detection, the cold mirror dew point instrument has a wide range of applications, such as measurement and detection, scientific research, military aerospace, pharmaceutical tobacco, industrial production and other fields.
The whole-process curve is displayed in real time to record the test time
Touch screen operation, Chinese interface, easy operation
Automatic balancing system, with a short measurement time
Mirror contamination self-detection function, manual way of cleaning the mirror
Data storage, query, and printing capabilities
Long-term stability, good reproducibility, you can do online analysis
The user can do single-point or multipoint calibration without software operation
Temp scale range |
-20℃ ~ + 95℃ (optional) |
Accuracy: |
±0.2℃ (optional ±0.1℃) |
Dew-point temperature sensor: | |
Temperature sensor: |
-40℃ ~ + 60℃ |
Precision: |
±0.1℃; resolution: 0.01℃ |
Repeatability: |
≤±0.05℃ |
Refrigeration mode: |
Secondary semiconductor Palpaste refrigeration |
Signal output: |
220VAC,50/60Hz; power: 60W |
Operating temperature: |
-20~50℃; Humidity: ≤ 95% |
Service life: |
Permanent free calibration |
