Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator

Tai'an Dearto Automation Instrument Co.,Ltd Verified Business License
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator thumbnail-1
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator thumbnail-2
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator thumbnail-3
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator thumbnail-4
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator thumbnail-5
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator photo-1
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator photo-2
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator photo-3
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator photo-4
Low Temperature -30 ~ 150 C Portable Dry Well Temperature Calibrator photo-5
US$ 2300 - 3500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
DEARTO
Place of Origin:
China
Model Number:
DTG-140G/150G
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DEARTO
Place of Origin China
Model Number DTG-140G/150G
Temperature Range -35℃~150℃
Usage Industrial
Theory Temperature Controller
Accuracy ≤±0.1℃
Product Overview
DTG low temperature portable intelligent dry block calibrator, simple operation, light and portable, accurate temperature control,suitable for laboratory and industrial site temperature calibration / measurement; its calibration temperature range can be from -35 ℃ to 150 ℃, the average temperature block uses high thermal conductivity Rate alloy material to ensure uniform and stable internal temperature field. The technology of temperature control accuracy, horizontal temperature field, vertical temperature field, stability, load performance and hysteresis are all at the domestic advanced level. Widely used in machinery,shipbuilding,chemical industry, food, electricity, medicine and other industries.
FEATURES AT A GLANCE
▶ Accurate temperature control and uniform temperature field
▶ Beautiful, portable and lightweight, convenient for on-site verification.
▶ Touch screen operation, one temperature rise, automatic temperature control is convenient to use.
▶ Multi-stage temperature control, rapid temperature rise, zero overshoot, fast and stable
▶ Multi-point calibration interpolation calibration technology for more accurate temperature control
▶ RS-232 interface for data export
▶ Temperature curve, volatility, deviation synchronous display, intuitive reading
Product Paramenters
Model
DTG-140G
DTG-150G
Temperature range
-15℃~140℃
-30℃~150℃
Heat source
Semiconductor cooling and heating
Control method
Touch screen
Display resolution
0.01℃
Standard dry block insertion aperture
Φ4.5,Φ6.5,Φ8,Φ10   When ordering, please indicate the insertion depth of the inspected sensor and the outer diameter of the inspected sensor (customization support)
Radial uniformity
≤0.2℃
Axial uniformity
Within 30mm from the bottom of the well ≤0.8 ℃
Temperature fluctuation
±0.15℃
Well depth
170mm
Dimensions
330 x 170x 320 mm
Power supply
110/220V,60/50Hz


Product Tags: dry well temperature calibrator , dry block temperature calibrator , dry body furnace
