HX-650FQ Automatic thermal ATM paper laminator and slitter machine
Video for operating this Automatic thermal ATM paper laminator and slitter machine:
1. /v_show/id_XMzg1Njg3NTc2.html
2./v_show/id_XMjA2MDE4MjEy.html
Main Technical Parameter (automatic thermal ATM paper laminator and slitter machine):
|
Model |
HX-650FQ |
|
Max Feeding Width |
650mm |
|
Main Engineer Power |
2.2kw |
|
Speed |
80m/min |
|
Size |
2400x1700x1300mm |
|
Weight |
1000kg |
|
Rewinding Diameter |
600mm |
|
Winding Diameter |
450mm |
|
Precision |
±0.1mm |
|
Power |
220V 50HZ |
Features (automatic thermal ATM paper laminator and slitter machine):
1. The max width: 650mm
2. The minimum slitting width: 8-25mm
3. Material thickness range: 0.05-3mm
4. Tolerence: 0.2mm, Precision: 0.1mm
5. The speed: 80m/min
6. Under CE and ISO
7. Manufacturer experience: 30years
8. Export experience: 20years
Charatertistics and Functions (automatic thermal ATM paper laminator and slitter machine):
1. This automatic thermal ATM paper laminator and slitter machine is slitting equipment of high precision and high sensitivity, with inflatable bearing used for feeding and receiving materials.
2. Imported magnetic powder clutch is adopted to control the tension.
3. Imported gas sensitive device is adopted to detect the rectification of rolling, with fully automatic hydraulic rectification control.
4. Automatic detection, rectification and metering can be realized.
5. It is characterized be accurate slitting, fast slitting speed, ease of operation and maintain
Purpose (automatic thermal ATM laminator and slitter machine):
1. It is applicable for the slitting tooling of industrial adhesive tape, electronic material, protective film, copper foil, aluminum foil, OPP, PE, PVC, sheet, cloth, etc.
2. This machine is widely used in the industries such as printing, packing, electronics, leather, clothes making, plastic, etc.
After-service (automatic thermal ATM paper laminator and slitter machine):
1. Warranty for machine: 12months
2. After-service: A reply within 24 hours
3. A free training in our factory available before delivering machines.
Relative roll automatic thermal ATM paper laminator and slitter machine, cutting machine, laminators ETC.
HX-650FQ automatic thermal ATM paper laminator and slitter machine
The exhibition (automatic thermal ATM paper laminator and slitter machine)
Packing detail (automatic thermal ATM paper laminator and slitter machine)
Our USP (Unique selling point):
Our factory is specializing in manufacturing and exporting cutting machines, slitting machines, laminating machines and die cutting machines with high quality and pretty competitive price. FREE SAMPLE training and testing will be available before shipping for your evaluation!
1) Own factory and professional manufacturer
2) Reasonable price
3) Implement strict quality testing and control procedure to make superior quality
4) Years of export experience
5) Customized color and logo are acceptable
6) Best service and punctual delivery
