China Factory Made BOPP Adhesive Packing Tape Jumbo Roll Slitting Rewinding Slitter Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1991
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Tape Film Paper Roll Slitting Cutting MachineNegotiableMOQ: 1 -
Multi-function Aluminum Foil Kitchen Food Stretch Film Plastic Wrap Rewinding MachineNegotiableMOQ: 1
-
Easy to Operate Small Paper Film Slitting MachineNegotiableMOQ: 1
-
Paper Product Processing Equipment Filter Paper Slitting and Rewinding MachineNegotiableMOQ: 1
-
Film and Aluminum Foil Slitting and Rewinding MachineNegotiableMOQ: 1
Product Description
1) PLC+touch screen, easy operation, labor-saving.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) eqipped with jumbo roll auto loading function, no need to loading the 250kg jumbo roll by manual
4) Running in a high automatization and intellectualization,no pollution
5) can add other device by your requirement, such as, auto labeling, sound-proof cover, moving receiving the waste edge etc.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) eqipped with jumbo roll auto loading function, no need to loading the 250kg jumbo roll by manual
4) Running in a high automatization and intellectualization,no pollution
5) can add other device by your requirement, such as, auto labeling, sound-proof cover, moving receiving the waste edge etc.
Model | HX-A1300Q |
Max.Diameter Of Unwinding | 800MM |
Max. Diameter Of Rewinding | 250MM |
Min Cut Width | 45MM |
Paper Core Diameter | 76.2MM |
Max Product Speed | 180 m/min |
Machine Dimension | 3300*1650*1470mm |
Feature
1 | The max width: 1300mm | ||||||
2 | Tolerence: 0.05mm, Precision: 0.1mm | ||||||
3 | Material thickness: 0.5mm-15mm | ||||||
4 | Kiss cut or cut through available | ||||||
5 | Under CE and ISO Certifications | ||||||
6 | Warranty for machine: 12months | ||||||
7 | Delivery time: 1-3days | ||||||
8 | Cut through for standard machine | ||||||
9 | Kiss cut is for optional | ||||||
Specification | 1300mm |
Max. Diameter Of Unwinding | 800 mm |
Max. Diameter Of Rewinding | 250 mm |
Min Cut Width | 45 mm |
Paper Core Diameter | 76.2mm |
Max Product Speed | 180 m/min |
Motor Power | 5.5KW |
Voltage | 380V 50HZ |
Air Pressure | 0.4→0.6MPa |
Machine Dimension | 3300*1650*1470mm |
Characteristics
1 | This machine employs microcomputer controller to set belt cutting length. | ||||||
2 | The cutting length is accurate. | ||||||
3 | Operation is easy. | ||||||
4 | Waste rate is low. | ||||||
5 | Manufacturing experience: 30 years | ||||||
6 | Export experience: 20 years | ||||||
