2021 Hot Sale Wet Pan Mill In Mine Mill Gold Grinding Mills For Sale

                                                                            Gold Grinding Machine

      The gold milling machine is mainly used for gold, silver, lead, zinc, iron, molybdenum, copper, antimony and other ores.

Gold grind machine is also called wet mill, wheel mill. It is mainly used for crushing equipment after the material is crushed. It is widely used in cement, silicate products, new construction materials, refractory materials, chemical fertilizers, ferrous metal processing, glass ceramics and other production industries. Dry or wet grinding of various ores and other grindable materials. The gold mill is easy to install and maintain, with small investment, high output, quick results, and low production costs. It is an ideal equipment for SMEs in mining areas.

The composition of the gold grind machine:
     The gold milling machine is mainly composed of power devices, racks, water basins, wheels, and disks. It adopts the wheel-type grinding working method: First, the motor transmits power to the reducer.

     Driven by the reducer, the large shaft The torque is transmitted to the upper horizontal axis, and then transmitted to the roller through the rods installed at the two ends of the horizontal axis, so that the roller generates driving force and performs counterclockwise rotation movement along the horizontal axis; the roller during work can surround the wet roller.

    The large vertical axis of the machine revolves, and it can rotate around the middle axis of the roller, while the roller is fixed. The added ore material is subjected to the squeezing force brought by the weight of the grinding wheel in the mill, and the huge friction force generated by the grinding wheel and the disc during the rotation of the grinding wheel.

      After being repeatedly squeezed, kneaded and ground, Crush thoroughly. While crushing and kneading minerals, the roller also has the function of mixing, stirring, and pulping. It fully mixes the material with water to make the grinding indexes such as pulp concentration stable. After grinding, the monomers dissociate the mineral fine particles.

    In the mixed slurry, it is taken to the upper surface and discharged through the overflow discharge port on the water basin. The overflow is discharged and processed in the next operation process. The coarse-grained minerals settle at the bottom of the pan and continue to grind.

    Crush until the fineness reaches the standard; the screen (the number of screens should be set according to the type of minerals, sorting requirements, and reasonable settings) at the discharge port of the basin can strictly control the classification particle size to avoid excessive crushing or Uneven granularity creates good conditions for subsequent operations.

Features of the gold grind machine :
     The gold milling machine mainly uses the raw material stirring, rolling, crushing, and rolling to achieve water balance, uniform mixing ratio, low air content, and improve the molding rate and molding quality. It has the characteristics of high density, good strength, and no porosity. High efficiency and energy saving, high output, this product is used for the recovery of tailings in the iron ore process, so that the ore powder is not lost and the effective resources are fully utilized.

Working principle of gold grind machine:
       The power of the gold milling machine is that the motor is transmitted to the gearbox through a V-belt, and the gearbox drives the mill to make the millwork run clockwise. When the raw materials in the water basin are running with the mill, the mill rotates with the mill to achieve the purpose of uniform mixing. At the same time, the raw materials are stirred, rolled, crushed, and crushed repeatedly with the grinding of the mill and the disk to achieve a certain degree of fineness and then discharged with water to achieve the purpose of beneficiation.
