A professional equipment used to produce construction sand. As an advanced artificial sand production tool, it can provide high-quality sand and gravel aggregates for various construction applications.
Key Applications:
Highway construction
High-speed railway projects
Building construction
Hydropower dam construction
Concrete mixing stations
Artificial sand production
Stone shaping
Typically integrated with complementary equipment like sand washing machines, stone crushers, and vibrating screens to form efficient sand production lines.
As a typical representative of sand making machines, the high-efficiency vertical shaft impact crusher delivers excellent performance in construction sand production.
| Parameter Type | Specific Parameters |
|---|---|
| Feed particle size | 60 - 600 mm |
| Motor power | 380 V, 50 Hz |
| Processing capacity | 60 - 600 tons/hour |
Hard stone enters the crusher and divides into two streams
One stream enters the impeller and ejects at high speed via centrifugal force
The other stream forms a ring-shaped vortex around the impeller
Materials collide violently with each other and chamber components
Finished product discharges for screening to required particle size
Dual crushing mechanisms: Combines impact crushing and friction grinding
Flexible feeding modes: Supports both central feeding and central cascade feeding
Adjustable operation: Can be customized according to production needs
High efficiency: Continuous crushing in swirling flow pattern
Large processing capacity of 60-600 tons/hour, meeting diverse production scale requirements with consistent output quality.
Patented impact angle design minimizes material-wear part friction, significantly reducing replacement part costs by up to 30%.
Advanced thin oil lubrication system with dual-pump injection and automatic monitoring ensures optimal equipment condition with minimal manual intervention.
Integrated vibration monitoring and automatic shutdown system provides instant anomaly detection and protection, maximizing operational safety.
Note: All specifications represent peak performance under optimal conditions. Actual results may vary based on material properties and operational parameters.
Different series of construction sand making machines vary in:
Tip: Match machine specifications to your raw material characteristics and production targets
Ideal for stable production sites
Consistent output requirements
Lower long-term operating costs
Perfect for multiple sites
Flexible transfer operations
Reduces material transport costs
Unsure about your production needs? Our experts will:
Analyze your specific requirements
Customize optimal sand making processes
Recommend ideal equipment configuration
| Model | VSI-7611 | VSI-8518 | VSI-9526 | VSI-1140 | VSI-1145 | |
|---|---|---|---|---|---|---|
| Capacity (t/h) | Cascade and Center Feeding | 120-180 | 200-260 | 300-360 | 450-520 | 500-600 |
| Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | 250-360 | |
| Feeding Size (mm) | Soft Material | |||||
| Hard Material | ||||||
| Rotation Speed (r/min) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | 1180-1280 | |
| Power of the Double Motors (kw) | 2x55 | 2x90 | 2x132 | 2x200 | 2x220 | |
| Overall dimension L*W*H (mm) | 4100×2290×2350 | 4600×2280×2650 | 4600×2350×2850 | 5200×2600×3220 | 5500×2790×3320 | |
| Power Source | 380v:50hz | |||||
| Vibrating Sensor | Inspection Scope:0.1-20mm/s, it can be adjusted continuously. | |||||
| Hydraulic Lubrication Station | Power of Double Oil Pump | 2x0.31kw | ||||
| Safety | Double oil pumps make sure supply of oil with; Stop automatically without oil flow or oil pressure; Water cooled; Heating start the motor in winter. | |||||
| Overall Dimension L*W*H (mm) | 820x520x1270 | |||||
| Power of Oil-Box Heater | 2kw | |||||
