CE Approval Grinding Gold Machine With Good Price

Good quality of grinding gold machine export to Africa

grinding gold machine will cooperate with materials and water to join in mixed , when they mix, the process will have a functions of stirring and squeezing, cone wet grinding machine can remove the air between materials, even stir, moistening, can make material to be grind fineness.

grinding gold machine Characteristics

grinding gold machine is the machine for grind gold, and less lost, high yield, convenient to move, less consumption energy, moderate price, easy operation, it is a machine for customers to beneficiation of gold, silver, lead, zinc, iron, molybdenum, copper, antimony, etc.

The grinding gold machine is a medium-sized wet milling equipment supporting the press. This machine is used for mixing and stirring high alumina or clay and other materials to make the water balance, and the proportion of various ingredients is uniform. The processing of the material by this machine can improve the molding rate.

The ladle of the grinding gold machine is a ferrule type. After one year of use, when changing the lapping machine of the grinding gold machine it is only necessary to change the outer hoops. Made and durable.

The power of the machine is that the motor is transmitted to the reducer through a V-belt, and then driven by the small bevel gear on the reducer and the large gear connected to the milling disk, so that the turntable runs counterclockwise. When the raw materials in the pan are moved along with the pan, the inner and outer scrapers are moved to achieve the purpose of uniform mixing. At the same time, the rollers floating on the beam are moved against the raw materials and the friction of the rollers to rotate the rollers, and the raw materials are strongly squeezed-crushed-squeezed-crushed (repeatedly) until the raw materials meet the user's requirements. At this time, the discharge scraper is lowered, and the raw materials flow out of the tray along the scraper to complete the purpose of mixing, stirring and squeezing.

Features of grinding gold machine

The grinding gold machine mainly uses the raw material stirring, rolling, crushing, and rolling to achieve water balance, uniform mixing ratio, low air content, and improve the molding rate and molding quality. It has the characteristics of high density, good strength, and no porosity. High efficiency and energy saving, high output. This product is used for the recovery of tailings in the iron ore process, so that the ore powder is not lost and the effective resources can be fully utilized.

Working process of the grinding gold machine

Selection method and process of gold milling machine when selecting gold

1 After the gold milling machine is installed and debugged, add about 5 kg of mercury to the bottom of the gold milling machine to start normal work.

2 Collect sands once per shift. Add 1 kg of mercury to collect the sands and mercury at the bottom of the shift. Receive the mercury in the gold-containing equipment. Twist the mercury out of the red cloth with a high density. Open the red cloth. What's left is Sands.

3 Add one kilogram of mercury to each shift. Containing one is a gold cloth or a gold blanket, and then put a mercury plate to collect gold.

Maintenance of grinding gold machine

1. The shaft bears the full load of the negative machine, so good lubrication has a great relationship with bearing life. It directly affects the service life and operating rate of the machine. Therefore, the injected lubricant must be clean and the seal must be good. Main oiling places: rotary bearings, roller bearings, all gears, movable bearings, sliding planes.

    2. Newly installed wheels are prone to loosening and must be checked frequently.

    3. Pay attention to whether the parts of the machine work normally.

    4. Pay attention to the degree of wear of the easy-wear parts, and pay attention to replacing the worn parts at any time.

    5. The plane of the bottom frame of the movable device should be out of dust to prevent the movable bearing from moving on the bottom frame when the machine encounters unbreakable materials, which will cause serious accidents.

    6. Bearing oil temperature rise, should immediately stop the inspection to eliminate the cause.

    7. If there is an impact sound when the gear is turned, it should be stopped immediately for inspection and eliminated.

Technical parameters of the grinding gold machine
