High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M thumbnail-1
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M thumbnail-2
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M thumbnail-3
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M thumbnail-4
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M photo-1
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M photo-2
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M photo-3
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M photo-4
US$ 26500 - 30000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
FAST CNC
Place of Origin:
China
Model Number:
LF60M
Contact Supplier Request Quote Chat Now
Jinan Fast CNC Machinery Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name FAST CNC
Place of Origin China
Model Number LF60M
Certification Other, ISO, CE
After-sales Service Provided Engineers available to service machinery overseas
Condition New
Control Software CYPCUT
Cooling Mode Water Cooling
CNC or Not Yes
Cutting Speed 120RPM
Cutting Area 6000mm
Cutting Thickness Φ10~φ210mm
Applicable Material Metal
Laser Type Fiber Laser

3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 0



ADVANTAGE

1. Professional pipe cutting machine

2. The newest pneumatic chuck

3. Easy to Operate



TECHNICAL DATA

MODEL LF60M

Pipe diameter range

(Diameter of circumscribed circle)

 Φ10~φ210mm
Max. Pipe length 6000mm
X-axis travel 330mm
Y-axis travel 6500mm
Z-axis travel 350mm
W-axis rotation angle n*360
W axis maximum speed 120RPM
X/Y axis positioning accuracy ±0.05mm
X/Y axis repeat positioning accuracy ±0.03mm
X axis maximum moving speed 40m/min
Y axis maximum moving speed 30m/min
X/Y maximum acceleration 1.0G
Chuck Pneumatic
Maximum load of chuck 200kg 35kg/m
Guide rail width 35MM
Lubrication type Automatic oiling
Lubrication type Automatic oiling
Power available 1000-3000W
Dimension 11900*1880*2260mm
Total Weight 4500kg



DETAIL IMAGES

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 1

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 2

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 3

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 4

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 5

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 6

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 7

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 8

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 9

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 10

SAMPLES

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 11

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 12

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 13

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 14

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 15

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 16



High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 17



High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 18

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 19

WHY CHOOSE US

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 20

COMPANY PROFILE

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 21

WORKSHOP

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 22

CUSTOMER VISIT

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 23

FAQ

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 24

CERTIFICATE

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 25

PACKING AND SHIPPING

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M 26
