Advantages
◆In accordance with different diameter and density of filter media, we use non-woven way and produce with rolling stitch which is multiple directional and layer gradient.
◆ Density of fibers increases gradually, which will block particles of various sizes in different density. It has a high dust-holding capacity.
◆Low cost together with long service life, will keep original shape under definitive air flow.
◆Different melting point of exterior and interior of the composite fiber makes connection points between fibers are firm and tight, not easy to fall off.
◆There are fully-viscous (three-dimensional treatment with glue), semi-viscous (surface treatment with glue) and non-viscous (no glue) filter to choose from.
◆Can be with galvanized steel or aluminum alloy frame, or add metal mesh as supporter to effectively prevent deformation under high-speed airflow.
◆Fireproof class: UL-900 Class 2.
◆Meet EN779:2012.
Material Instructions
◆Media: Polyester fiber.
◆Frame: Galvanized steel, aluminum alloy frame with metal mesh as supporter in the air outlet side.
◆Temperature: Maximum 90°C in continuous service.
Application
◆Suitable for the air supply system at top of the spraying-baking booth, painting factory and baking finish house to ensure a high degree of cleanliness and air-distribution uniformity. Traps small dust particles and preventing pollution of paint.
|
Common Specifications | |
Model |
HCF-600G |
Common Size |
22mmT×2m×20m |
Ingredient |
Polyester |
Gram Weight |
600 g/m2 |
Capacity of Dust Arrestment |
400 g/m2 |
Norm Velocity |
0.26 m/s |
Heat Resistance |
120 ºC |
Fire-resistance Class |
Class F1 DIN53438 |
Average Trapping Efficiency |
97~99% |
Initial Pressure Drop |
26 Pa |
Final Pressure Drop |
400 Pa |
Note: 1. In case of specifications or structures changes, HEFIL will provide up-to-date data on website: .
2. HEFIL makes various of other models’ HCF filter not listed in above table. Please consult with us if you need.
