Water Drinking Cup Making Machine Water Glass Cups Making Machine Water Plastic Cup Making Machine

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Hot Product

Product Description

Model	FJL-SZ-680 I	FJL-SZ-680 II		FJL-SZ-750 I		FJL-SZ-750 II
Max. Forming Area	650×320mm			750×420mm
Max. No-Load Speed	35 Cycles/min
Running Pattern	Hydraulic
Oil Pump Motor Power	5.5KW(Double Pump)			15KW(Double Pump)
Cutting Pattern	In mould automatic
Feeding Pattern	Motor with Encode	Servomotor		Servomotor		Servomotor
Stretching Pattern	Air Cylinder	Servomotor		Air Cylinder		Servomotor
Sheet Materia	PP.PS.HIPS.PET.PVC
Sheet Thickness Range	0.2-2mm
Max. forming Depth, Sample Height	120mm			150mm
Max. Sheet Roll Dia	800mm
Heater arrangement	(120Pieces,650W)Top+Bottom Heating With IR Cerami cHeater			(152Pieces,650W)Top+Bottom Heating With IR Cerami cHeater
Temperature Controller & Thermocouple	PID K-Type
Electrical Consumption	40KW/h		45KW/h	50KW/h		55KW/h
Overall Power	100KW		110KW	120KW		130KW
Air Consumption	1.5-1.8m³/min, 0.6-0.8 Mpa			2-2.5m³/min, 0.6-0.8 Mpa
Dimension	L3650×W1950×H2500mm			L4000×W1730×H2600mm
Weight(T)	4.4T		4.5T	4.8T	5T
Power Supply	380V/50HZ Three phase four wires

1.The operation is controlled by PLC with touch screen

2.Adopt four pillars to fix the mould

3.Fill oil automatically to lubricate mechanism movement at certain time

4.Temperature control modules to control each temperature area

5.Machine production process started from sheet feeding, heating, stretching, forming

in-mould cutting in one stroke

6. Convenient operation, outstanding performance, low noise and high quality
