Distribution Cable
Excellent characteristics, content with different requirement indoor, Include: buildings,lift well,FTTD.
It can supply bandwidth, transmission speech,data,TV and image. Characteristic: small diameter,light
weight,flexibility. So it Is easy to installation,maintenance and manage.
Parameters
|
Fiber Count |
Cable Dimension mm |
Cable Weight kg/km |
Tensile N |
Crush N/100mm |
Min. Bend Radius mm |
Range of Temperature
|
|||
|
Long Term |
Short Term |
Long Term |
Short Term |
Dynamic |
Static |
||||
|
4 core |
5.0 |
17 |
100 |
200 |
200 |
1000 |
20D |
10D |
-20-+60 |
|
6 core |
5.2 |
21 |
100 |
200 |
200 |
1000 |
|||
|
8 core |
5.5 |
28 |
130 |
440 |
200 |
1000 |
|||
|
12 core |
6.5 |
35 |
200 |
660 |
200 |
1000 |
|||
|
16 core |
7.5 |
44 |
200 |
660 |
200 |
1000 |
|||
|
24 core |
8.2 |
60 |
200 |
1000 |
200 |
1000 |
|||
|
48 core |
12.5 |
130 |
300 |
1000 |
200 |
1000 |
|||
|
Note: 1. All the values provided in the table, which are for your reference, are subject to change without notice; 2. The cable dimension and weight are in accordance with tight-buffered fiber withφ0.9mm outer diameter; 3. D is outer diameter of the round cable; 4. The minimum bend radius (static) is 5D when G.657 fiber is used. |
|||||||||
