Brand compatible 10gbps SFP+ module SR TRx 850nm 300m transceiver
- 1000 per Month
- T/T Credit Card
-
40G QSFP+ to QSFP+ Active Optical Cable Four-channel full-duplex active optical cable
-
10G 40G SFP+ QSFP+ copper patch cord
-
General compatible 100G QSFP28 to 4xSFP28 DAC breakout cable direct attach cable
-
QSFP-40G-SR4 Compatible MMF 850nm 150m MPO 40gbase qsfp sr4
-
QSFP+-40G-ER4 qsfp 40km 40g mode 1550nm
-
40G QSFP+ 1310nm 10KM qsfp-40g-lr4
Product Description
Brand compatible 10gbps SFP+ module SR TRx 850nm 300m transceiver
Rollball's RSFPP-85192-SRD optical transceiver are designed for 10Gb/s serial optical interfaces for data communications with multimode fiber (MMF). The transceiver can support 1.25Gb/s to 11.1Gb/s.
The transceiver designs are optimized for high performance and cost effective to supply customers the best solutions for data-com and storage applications.
Features
Optical interface compliant to IEEE 802.3ae
Hot Pluggable
Up to 300m on 50/125um MMF(2000MHZ.KM)
850nm VCSEL transmitter, PIN photo-detector
SFP MSA package with duplex LC connector
Low power consumption
Very low EMI and excellent ESD protection
+3.3V single power supply
Cost effective SFP+ solution, enables higher port densities and greater bandwidth
Operating case temperature: 0 to 70 °C
Applications
10G Base-SR/SW
10G Fiber Channel
Other optical links
Ordering information
SFP+ (10G) | ||||||
RSFPP-85192-SRD | 10G | 850 | 300M | SFP+ | 0~70 | VSCEL+PIN |
RSFPP-31192-LRD | 10G | 1310 | 10KM | SFP+ | 0~70 | DFB+PIN |
RSFPP-55192-ERD | 10G | 1550 | 40KM | SFP+ | 0~70 | EML+PIN |
Rollball International Co.,Ltd, specialized in providing high performance fiber optic communication products and accessories for telecommunication, broadcast, CATV and network industry worldwide. With more than 10 years of industry experience, Rollball brand products have covered all areas of fiber optic transmission, International sales steadily, the products are exported to more than 200 countries and regions.
Mob / Whatsapp / Wechat: +86 15971526204
Skype: sales013.rollball
We sincerely invite all interested buyers to visit our company and contact us directly for further information, we will reply you as soon as possible!!!
