40G QSFP+ to QSFP+ Active Optical Cable Four-channel full-duplex active optical cable
- 1000 per Month
- T/T Credit Card
Product Description
40G QSFP+ to QSFP+ Active Optical Cable
Description
- Rollball’s QSFP+ active optic cables are a high performance, low power consumption, long reachinterconnect solution supporting InfiniBand QDR/DDR/SDR,12.5G/10G/8G/4G/2G fiber channel ,PCIe and SAS. It is compliant with the QSFP MSA and IEEE P802.3ba. The Olink QSFP AOC is an assembly of 4 full-duplex lanes, where each lane iscapable of transmitting data at rates up to 11.3Gb/s, providing an aggregated rate of 45.2Gb/s. The Olink QSFP+AOC is one kind of parallel transceiver which provides increased port density and total system cost savings.
Features
- Four-channel full-duplex active optical cable
- Transmission data rate up to 11.3Gbit/s per channel
- Reliable VCSEL array technology using multimode fiber
- Available in standard lengths of 3, 5, 10, 15, 20, 30, 50,100m
- Low power consumption <1.5W
- Operating case temperature 0°C to +70°C
- 3.3V power supply voltage
- RoHS 6 compliant
- Hot Pluggable QSFP form factor
Applications
- Infiniband QDR/DDR/SDR
- Datacenter
- 40G Ethernet
- 4G/8G/10G Fibre Channel
Order information
P/N | Parameters |
RQSFP-40G-AOC1M | QSFP-40G AOC-1m;DDM;0ºC ~ +70ºC/-40ºC ~ +85ºC |
RQSFP-40G-AOC2M | QSFP-40G AOC-2m;DDM;0ºC ~ +70ºC/-40ºC ~ +85ºC |
RQSFP-40G-AOC3M | QSFP-40G AOC-3m;DDM;0ºC ~ +70ºC/-40ºC ~ +85ºC |
Specification
Optical characteristics
The following optical characteristics are defined over the Recommended Operating Environment unless otherwise specified.
| Unit | Values |
Operating Reach | m | 10K |
Transmit | ||
Center wavelength (range) | nm | 1260 -1355 |
Side Mode Suppression Ratio (min) | dB | 30 |
Launched power | ||
– maximum | dBm | +0.5 |
– minimum | dBm | -8.2 Notes1 |
- OMA | dBm | -5.2 |
- OMA-TDP (min) | dBm | -6.2 |
Transmitter and dispersion penalty | dB | 0 Notes4 |
Average launch power of OFF transmitter (max) | dBm | -30 |
Extinction ratio (min) | dB | 3.5 Notes2 |
RIN12 OMA (max) | dB/Hz | -128 |
Optical Return Loss Tolerance (min) | dB | 12 |
Receiver | ||
Center wavelength (range) | nm | 1260-1355 |
Receive overload (max) in average power1 | dBm | 0.5 |
Receive sensitivity (min) in average power1 | dBm | -14.4 Notes3 |
Receiver sensitivity (max) in OMA (footnote 2) | dBm | -12.6 Notes3 |
Receiver Reflectance (max) | dB | -12 |
Stressed receiver sensitivity (max) in OMA2 | dBm | -10.3 |
Vertical eye closure penalty (min)3 | dB | 2.2 |
Stressed eye jitter (min)2 | UIp-p | 0.7 |
Receive electrical 3dB upper cutoff frequency (max) | GHz | 12.3 |
Receiver power (damage, Max) | dBm | 1.5 |
- Quality system of ISO900,CE,FCC,ROHS registration
- Manufacture system
- R&D system
- Purchasing system
- Prompt delivery and remarkable services
- Reasonable prices
- Accept orders according to customer's demands
- Rich experience of OEM & ODM co-operation
- Shipment,payment and delivery
We sincerely invite all interested buyers to visit our company and contact us directly for further information, we will reply you as soon as possible!!!
