fiber optic media converter rj45 sc connector communication
Media converters are flexible and cost-effective devices for implementing and optimizing fiber links in all types of networks. The most common type of media converter is a device that functions as a transceiver converting the electrical signal used in copper Unshielded Twisted Pair (UTP) network cabling into light waves used in fiber optic cabling.
Key Feature:
-10/100/1000Mbps Ethernet
-10/100/1000 BASE-T/TX electrical port
-1000 BASE-SX/LX optical port
-Electrical port supports Auto-Negotiation for 100Mbps or 1000Mbps, full duplex or half duplex data.
-Optical port supports 1000Mbps full duplex data
-Automatic MDI/MDI-X crossover
-Distances up to 2km for Multi mode;Up to 120km for Single mode
-Voltage transient protection on all power and signal input.output lines provides unconditional protection from power surges and other voltage transient events
-No in-field optical adjustments required
|
Parameters |
Specifications |
|
Optic Wavelength |
NF-C2200SX: 850nm NF-C2200LX20: 1310nm NF-C2200-SFP: N/A NF-C2200LX20A:TX:1310nm/RX:1550nm NF-C2200LX20B:TX:1550nm/RX:1310nm |
|
Transmission Distance |
Multimode: 2km Single mode:10km~120km |
|
Port |
One RJ45 port, Single fiber port (SC/ST/FC Optional) |
|
MDI/MDI-X |
Auto selection |
|
Forward / Filter Rate |
10M: 14,880/14,880pps |
|
Power Supply |
External : 5V DC 2A Power Consumption : ≤5W |
|
Operating Temperature |
0 °C to +70 °C |
|
Storage Temperature |
-20 °C to +80 °C |
|
Relative Humidity |
5% to 90% (non-condensing) |
|
Emissions |
FCC , Class A, RoHS, CE Mark |
|
Product Categories (Please click on more information) |
||
| Fiber Optic Cables | Fiber Optic Components | FTTH Solutions |
| Fiber Optic Management | Fiber Optic Equipment | Networking Products |
>>>>>>Contact Us
Shenzhen Skylynn Communication Ltd. have CE, RoHS and ISO9001 certificate. Now, we are going to do the Antel certificate.
