FTTH France Double Sheath Indoor/Outdoor 4.6mm 6mm 500m G657A2 Fiber Optical Drop Cable 1fo Fiber Optic Cable
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
1999
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Green Patch Cord SC APC 1.6mm 3.5meter Singlemode Simplex Fiber Optical Cable Jumper Patch CordNegotiableMOQ: 1 -
Fiber Optic Cleaner One Click Optical Fiber Cleaning Pen SC LC MPO 1.25mm 2.5mm Connector Ferrule CleanNegotiableMOQ: 1
-
1.6mm Sc/apc Jarretiere Optique Fibres sm Core Simplex Scapc Green 3.5m White Fiber Optical 1.6mm Patch CordsNegotiableMOQ: 1
-
1.6mm 3.0mm sm Aqua Patch Cable 9/125 Sc/apc to Sc/apc 1.5m 3.5m White Simplex Optical Fiber Patchcord scNegotiableMOQ: 1
-
Outdoor Non-armored Singlemode G652d 6 12 48 Core Armoured Fiber Optic Cable GyftyNegotiableMOQ: 1
FTTH France double sheath Indoor/Outdoor 4.6mm 6mm 500m G657A2 Fiber optical Drop Cable 1fo fiber optic cable
Product Description
Double Sheathed drop cable is a multi-purpose drop cable enabling simple, dast and reliable outdoor-indoor transitions. With a rugged and watertight construction, the double sheathed drop cable offers high mechanical performances. This optical cable is designed for artial roll-outs(spans up to 70m), but it can also be pulled into ducts, on several hundred meters.
Offering a double sheathed construction, the cable drop range presents twp ripcords enabling to strip off the HDPE outer sheath in a couple of seconds. Thanks to this operation a Low Smoke Zero Halogen Flame Retardant drop cable can be then used for indoor applications.
No splice is thus required to make the transition between the outdoor optical drop and the indoor one. The cable enables the transmission of optical signal from an outdoor distribution point to a telecommunications outlet without weighing down the optical budget.
Features & Benefits:
• Enables simple, fast and reliable outdoor-indoor transitions;
• One drop for aerial, duct and indoor FTTH installations;
• Wide operating temperature range;
• Integrated in a comprehensive FTTH solution including aerial & fecade
hardware and transition box, customer terminal box, fibre distribution box and
optical telecommunications outlets.
Specification:
|
Fibre type
|
Fully compliant with G657A1/A2 ITU
recommendations
|
||
|
Fibre cores
|
1FO
|
2FO | 4FO |
|
Buffer
|
900µm micro-bundle
|
||
|
Diameter
|
3mm/4.5mm/6mm | ||
|
Weight
|
29kg/km
|
30kg/km
|
|
|
Outer Sheath Material
|
HDPE Black RAL 9005
|
||
|
Inner Sheath Material
|
LSZH-FR White RAL 9010
|
||
|
Cable Reinforcement
|
Aramid yarns, 2FRP cores
|
||
Packing:
|
Description
|
Package
|
|
1FO outdoor/indoor drop cable
|
500meters per drum
|
|
2FO outdoor/indoor drop cable
|
|
|
4FO outdoor/indoor drop cable
|
