LNF66 RS485 Communication Embedded Multifunction Smart Energy Meter
- T/T Credit Card
You May Like
-
LNF31 72*72mm Digital Single Phase Panel Mounted Energy Meter
-
LNF32 Ultra-thin Single Phase RTM Real-time Measurement Smart Energy Meter
-
LNF33 Three Phase Current Panel Mounted Smart Energy Meter
-
LNF33 72*72mm Three Phase Panel Mounted RTM Real-time Measurement Energy Meter
-
LNF26 Smart Building LCD Display 96x96 Panel Mounted Voltage Digital Energy Meter
-
LNF56 96*96 LCD Display 3 Phase Multi-functional Panel Energy Meter
Product Description
Product Name:LNF66 RS485 communication embedded multifunction smart energy meter
LNF66 multifunction power meter can measure all electrical parameters and bi-directional electric energy, with functions such as communication and energy pulse output. The instrument adopts ultra-thin design and is easy to be installed. As an advanced intelligent and digital grid front-end acquisition component, it can be applied for power monitoring systems and energy management systems to realize power data collection.



Accuracy | Voltage, current: 0.2%;power: 0.5%,frequency:±0.01HZ;Active energy:0.5s | |
Data update rate | 1s | |
Signal Input | Rated current | AC 1A,5A |
Rated voltage | AC 100V,380V | |
Overload | Continuous:2In,instantaneous:10In/5s Continuous:1.2Un,instantaneous:2Un/1min | |
Energy consumption | ≤0.1VA | |
Fequency | 45~65HZ | |
Communication | RS485 interface | Modbus-RTU protocol, baud rate up to 9600bps |
Energy pulse | Optocoupler isolation ,pulse width 80ms±20% | |
Digital Input | Optocoupler isolation ,passive dry contact | |
Relay Output | Contact capacity AC250V 5A or DC 30V 5A | |
Auxiliary power supply | Working range | AC/DC 80~270V |
Energy consumption | ≤5VA | |
Environment condition | Working temperature | -10~55℃ |
Storage temperature | -25~70℃ | |
Relative humidity | ≤93%RH | |
Altitude | ≤2500m | |
Safety | Insulation | Signal power supply output terminal to case resistance ≥100MΩ |
Withstand voltage | Power supply,input and output ≥2kv | |
Protection level | IP54 |

■Intelligent building
■Public facility
■Industrial and mining enter enterprise
■Panel Meter



SMT AOI Test Plug-In Mounting



Wave Soldering Assembling Inspection


Q: Are you trading company or manufacturer ?
A: We are factory located in Jiangyin Jiangsu Province.
Q: Does your company provide customized manufacturing?
A: We provide OEM/ODM service to our customers. Our experienced R&D team will give our customer solution in a high efficiency way.
Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.
Q: Do you provide samples ? Is it free or extra ?
A: You need to pay for the sample and cover the freight as well.
Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
