96x96 Panel Mounted RS485 Comm 3 Phase Multi Functional Digital Multimeter Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Ultra-thin Design 3 Phase RS485 Multifunctional Digital Panel Volt Ampere Meter AC 1A/ 5A AC 100V/380V Digital Only 96*96*34mmNegotiableMOQ: 1 -
67x67 Panel Mounted Digital 3 Phase Current Led Power MeterNegotiableMOQ: 1
-
72*72 3 Phase Digital Electricity Ampere Meter Panel Mount AmmeterNegotiableMOQ: 1
-
LNF31 72*72mm Single Phase Panel Mounted Micro Ampere MeterNegotiableMOQ: 1
-
LNF32 96*96 Electric Rs485 Panel Mounted Digital Power Ampere MeterNegotiableMOQ: 1
Product Description
Product Name: 96x96 panel mounted RS485 comm 3 phase multi functional digital multimeter price
This series of multi-function power meters support all-parameter measurement, bi-directional energy metering, four-quadrant reactive metering and harmonic analysis. they can be connected to power monitoring system and energy management system to realize remote data monitoring.
Technical Parameter
Accuracy | Voltage, current: 0.2%;power: 0.5%,frequency:±0.01HZ;Active energy:0.5s | |
Data update rate | 1s | |
Signal Input | Rated current | AC 1A,5A |
Rated voltage | AC 100V,380V | |
Overload | Continuous:2In,instantaneous:10In/5s Continuous:1.2Un,instantaneous:2Un/1min | |
Energy consumption | ≤0.1VA | |
Fequency | 45~65HZ | |
Communication | RS485 interface | Modbus-RTU protocol, baud rate up to 9600bps |
Energy pulse | Optocoupler isolation ,pulse width 80ms±20% | |
Digital Input | Optocoupler isolation ,passive dry contact | |
Relay Output | Contact capacity AC250V 5A or DC 30V 5A | |
Auxiliary power supply | Working range | AC/DC 80~270V |
Energy consumption | ≤5VA | |
Environment condition | Working temperature | -10~55℃ |
Storage temperature | -25~70℃ | |
Relative humidity | ≤93%RH | |
Altitude | ≤2500m | |
Safety | Insulation | Signal power supply output terminal to case resistance ≥100MΩ |
Withstand voltage | Power supply，input and output ≥2kv | |
Protection level | IP54 |
Related Products
Application
■ Smart equipment
■Intelligent building
■Public facility
■Industrial and mining enter enterprise
■Panel Meter
■Intelligent building
■Public facility
■Industrial and mining enter enterprise
■Panel Meter
