DC12V Relay Module Adjustable Trigger Time Delay Relay Module Programmable Timer Relay With Case

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

1.Product attributes

Specifications:

Relay	AC 220V 10A or DC 30V 10A
Quiescent Current	20mA
Operating Current	50mA
Working Voltage	10-16V (if other ranges can be customized)
Signal Voltage	4V-20V (if other ranges can be customized)
Life	about 100,000 times
Working Temperature	-40 to 85 °C.
Size	Approx. 62.4x34.8x18.5mm

Features

1. New upgrades to simplify,to meet customer needs.

2. Increase the supply anti-reversefunction.

3. The use of opto isolated input and output,enhanced anti-jamming capabilit

consumption.

4. Set parameter after power for ever memories.

5. Signal terminal voltage signal can be maintained for a longtime.

6. to ensure stability,industrial grade board,class PLC.

Working mode selection:

After power on,long press K12 seconds later into the select function mode,P1-1~P1-4forchoose.

P1-1 operating modes:a signal to trigger relay, time is up,the relay disconnect users,You can set relay time T,click K2 the hundreddigital tube starts flashing,then press K3, the hundred digital change;click K2 ten digital tube starts flashing,then press K3,ten digit changes;click K2 bit digital tube starts flashing, then press K3, single-digit change;then

click K2,; digital pipe does not blink,then press the K3, shifting the decimalpoint,the decimalpointin abitindicates 0-999minutesin ten represents 0 to 99.9 seconds withou tadecimalpointrepresents 0-999 seconds;goodchoice,bringing the time setting is completed.Short press K1,enterfunction offine-tuning settings,triggerthedefaultdelayperiod is invalid, press K1, during the delay trigger active(re-timing),clickon the K1, during the delay reset (timer turned off,the relay reset) press

again to repeat the default settings for the first time.

P1-2 operating modes:Asignal trigger ,digital countdown begins,X seconds after,there lay open Y seconds,then close.Users can set the relay time X,Y;P1-1different time settings similar to the blue lights that set the relay time,blue light indicates setting relay off time. Short press K1, enter function offine-tuning the set,the default trigger is invalid during

the delay,pressK1,during the delay trigger active(re-timing),then click the first repeat default settings.

P1-3 operating modes:Open X seconds,disconnect Yseconds, infinite loop.Users can set the relay timeX,Y;time setting similar to P1-2.Short press K1,enter function offine-tuning set,The default function is:set up an electric circuit the relay first open, press the K1,there lay first close.Press again to repeat the default functionality.

P1-4 operating modes:a signal to trigger the relay open but do not start the timer,when the trigger signal disappears,digital count down begins,X time after,the relayclose; During the delay,again to the signal,digital

count down canceled, stays energized, the signal disappears, restart count down; (equivalentto release the button to start timing, commonly usedin power-offdelay).Users canset the relay time X; time setting similar to P1-1.

2.Product display
