SL Series Heavy Duty Slurry Pump Metal Lined

SL Series Heavy Duty Slurry Pump Metal Lined thumbnail-1
SL Series Heavy Duty Slurry Pump Metal Lined photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
CNSME
Place of Origin:
China
Model Number:
SL150E
Contact Supplier Request Quote Chat Now
Shijiazhuang Minerals Equipment Co. Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
3 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CNSME
Place of Origin China
Model Number SL150E
Application Other
Power Electric
Theory Centrifugal Pump
Standard or Nonstandard Standard
Structure Single-stage Pump

Certificate: CE/ISO

Place of Origin: Hebei, China

● Outlet(mm) :150

● Flow rate :486-1115m3/hr

● Head H(m): 12-51.5

● Speed: 800-1500rpm

● Efficiency:Max65%

● Materials: Impeller A05

● Impeller:5-Vane Closed Type

● Vane Diameter(mm):381

● Power: Max 120Kw

● Color: Depend on customers’ requirements

● NPSH (m):5-8

● Warranty: 1 year Warranty (except wet-end parts)

1. Introduction:

General Introduction:

▶Our horizontal slurry pumps are designed for heavy-duty applications such as mining, minerals processing, mill discharge, power plants, tailings, and other industrial applications, for maximum abrasion, erosion, and corrosion resistance.

▶The pumps are in a wide range of sizes, available with both high chrome and rubber wearing parts. Components like impeller and volute come in a range of hard metal types and elastomers to suit the specific application.

▶Different shaft seal types are available to suit every requirement, including gland packing seal, expeller seal, and mechanical seal.

▶Our metal-lined slurry pumps are designed for heavy-duty industrial applications, to handle the most arduous slurries.

▶Wear resistant cast alloys are used for slurry pump liners and impellers where conditions are not suited to rubber, such as with coarse or sharp-edged particles, or on duties having high impeller peripheral velocities or high operating temperatures.

▶Designed for rugged duties while offering higher efficiencies, the SL series is a combination of the SH pump’s unique features.

▶The SL series provides the widest range of hydraulics from the 20mm to 550mm discharge pumps. The 20mm pump is perfect for the laboratory or in demonstration plants.

2. Specifications:

Pump

Model

Outlet

(mm)

Allowable

Max. Power (kW)

Material

ClearWater Performance

Impeller

Capacity Q

Head

H(m)

Speed

n(r/min)

Max.Eff.

η%

NPSH

(m)

No. of

Vanes

Vane Dia.

(mm)

Impeller

m3/h

l/s

SL/20A

20

7.5

Metal

(A05)

2.34-10.8

0.65-3

6-37

1400-3000

30

5

152.4

SL/50B

50

15

16.2-76

4.5-20

9-44

1400-2800

55

190

SL/75C

75

30

18-151

5-42

4-45

900-2400

57

2290

SL/100D

100

60

500-252

14-70

7-46

800-180

60

2-3.6

305

SL/150E

150

120

1115-486

32-135

12-51.5

800-1500

65

2-6

381

SM/200E

200

120

666-1440

185-400

14-60

600-1100

73

4-10

549

SM/200F

200

260

666-1440

185-400

14-60

600-1100

73

4-10

549

SL/250E

250

120

396-1425

110-396

8-30

500-800

77

2-10

550

SL/300S

300

560

468-2538

130-705

8-60

400-950

79

2-10

653

SL/350S

350

560

650-2800

180-780

10-59

400-840

81

3-10

736

SL/400ST

400

560

720-3312

200-920

7-51

300-700

80

2-10

825

SL/450ST

450

560

1008-4356

280-1210

9-48

300-600

80

2-9

933

SL/550TU

550

1200

1980-7920

560-2200

10-50

250-475

86

4-10

1213



Driven Type:

DC(z): The pump and the engine are directly connected by a coupling.

Belt-driven Types: The pump and the engine is connected by pulleys and belts — CV, CR(z), ZV(z).

SME SH/SL Slurry pumps are designed for the toughest slurry applications
